Ubiquiti

Ubiquiti LAP-GPS-AU | airMAX Lite AP GPS 5 GHz Sector Access Point, AU

Ubiquiti LAP-GPS-AU | airMAX Lite AP GPS 5 GHz Sector Access Point, AU

SKU:LAP-GPS-AU

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Ubiquiti LAP-GPS-AU airMAX Lite AP GPS is a 5 GHz sector access point built for long-distance point-to-multipoint wireless broadband. This AU region variant adds GPS synchronisation, allowing TDMA sync across multiple sites to reduce self-interference and increase network capacity. It offers a 90 degree beamwidth, real TCP/IP throughput above 450 Mbps and link ranges beyond 12 km.

The integrated high-isolation shielded antenna reduces out-of-band energy, and a dedicated spectral analysis radio helps identify clean channels. A separate 2.4 GHz management radio supports setup from a mobile app, and the ball-joint mount speeds up installation. The access point runs airOS 8 and is powered over passive PoE through a Gigabit Ethernet port.

Order now at iptrading.com.au, trusted by Australian IT professionals.

Features

- Integrated GPS sync with TDMA GPS synchronisation
- High-isolation shielded antenna design that reduces out-of-band energy for greater system capacity
- Dedicated spectral analysis radio
- Ball-joint mount for versatile mounting and quick installation
- Separate Wi-Fi management radio for mobile app setup
- Runs airOS 8
- Gigabit Ethernet wired connection

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Model: LAP-GPS (AU regional variant)
- Operating frequency: 5150-5875 MHz
- Management radio: 2412-2472 MHz
- Networking interface: 1 x 10/100/1000 Ethernet port
- Power supply: 24V, 0.3A Gigabit PoE adapter
- Power method: Passive PoE, supported voltage range 20-26VDC
- Antenna: 90 degree beamwidth sector, high-isolation shielded
- Throughput: up to 450+ Mbps real TCP/IP
- Link range: 12+ km
- Client capacity: 50+ clients
- Maximum TX power: 25 dBm
- Maximum power consumption: 7.1W
- Dimensions: 360.98 x 124.57 x 71.28 mm
- Weight: 752 g

FAQs

Q: What does the GPS in the LAP-GPS-AU do?
A: The integrated GPS provides TDMA synchronisation between multiple airMAX access points, which reduces interference between co-located units and improves overall network capacity.

Q: What frequency band does the LAP-GPS-AU operate on?
A: It operates in the 5 GHz band, covering 5150-5875 MHz. A separate 2.4 GHz radio is used only for management and mobile app setup.

Q: How is the LAP-GPS-AU powered?
A: It is powered by passive PoE at 24V using the included Gigabit PoE adapter. The supported input voltage range is 20-26VDC.

Q: What is the coverage pattern and range?
A: It uses a 90 degree beamwidth sector antenna and supports link ranges of 12 km or more, with capacity for 50+ clients.

Q: What is the difference between the LAP-GPS-AU and other Lite AP models?
A: The LAP-GPS adds integrated GPS synchronisation for TDMA operation, which is not available on the standard Lite AP. The AU suffix denotes the Australian regional variant.

Q: What software does it run and how is it configured?
A: It runs airOS 8. The dedicated management radio lets you set it up from a mobile app during installation.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
