• Silver SFP-100MFX-BCC transceiver with blue fiber connector and Blue Cable Co label
1 1

Blue Cable Co

SFP-100MFX-BCC | Dell Compatible 100MB Multi-Mode - 2km (100BASE-FX)

SFP-100MFX-BCC | Dell Compatible 100MB Multi-Mode - 2km (100BASE-FX)

SFP-100MFX-BCC

In stock:16

$36.94 AUD
$36.94 AUD
$36.94 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The SFP-100MFX-BCC is a drop-in compatible replacement for the Dell SFP-100MFX and 407-BBOT. This plug-and-play transceiver delivers 100BASE-FX connectivity for Dell networking switches and routers. - 100BASE-FX compliance guarantees IEEE 802.3 Fast Ethernet interoperability at 100 Mbps - SFP form factor with duplex LC connector, 1310nm wavelength, up to 2km reach over multi-mode fibre - Digital Diagnostic Monitoring (DOM) support for real-time transceiver parameter access via SNMP - Hot-pluggable design allows field installation without interrupting network operation - Commercial operating temperature range: 0 to 70C case temperature - Available as SFP-100MFX or 407-BBOT variant to match your existing Dell inventory

Features

• IEEE 802.3 100BASE-FX compliance ensures full interoperability with Fast Ethernet infrastructure at 100 Mbps data rate
• 1310nm FP laser transmitter and PIN photodetector pair optimized for multi-mode fibre transmission with 2km optical budget
• SFF-8472 compliant digital diagnostics provide real-time monitoring of temperature, laser bias current, transmit power, receive power, and supply voltage via two-wire serial interface
• Hot-pluggable SFP MSA form factor allows installation and removal without powering down the host switch or router
• Commercial temperature range (0 to 70C case temperature) suits standard data centre and enterprise network environments
• Duplex LC connector interface ensures secure, low-loss coupling to 50/125um or 62.5/125um multi-mode fibre patch cables
• Low power consumption design reduces thermal load on switch chassis and supports high-density SFP port configurations

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we"ll deliver a replacement part before you return the faulty item,minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-100MFX-BCC
Compatible Replacement For: SFP-100MFX, 407-BBOT
Compatibility: Dell compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP (Small Form-Factor Pluggable)
Data Rate: 100 Mbps (100BASE-FX)
Wavelength: 1310nm
Fibre Type: Multi-Mode Fiber (MMF)
Connector Type: Duplex LC
DOM Support: Yes (Digital Diagnostic Monitoring)
Standards: IEEE 802.3 100BASE-FX, SFP MSA, SFF-8472 (DDM)
Max Reach: Up to 2km (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0 to 70C (commercial)

FAQs

Q: Will this work in place of the Dell SFP-100MFX or 407-BBOT?
A: Yes. This transceiver is engineered to the same 100BASE-FX standard, SFP form factor, and electrical interface as the Dell SFP-100MFX and 407-BBOT. It provides plug-and-play compatibility with Dell networking equipment that accepts these part numbers.

Q: Which Dell switches and routers support this 100BASE-FX SFP transceiver?
A: This transceiver works in Dell Networking and PowerConnect switches with SFP slots that support 100BASE-FX. Compatibility is determined by the switch supporting 100 Mbps Fast Ethernet over fibre on its SFP ports. Consult your switch datasheet to confirm 100BASE-FX support on the target port.

Q: What type of fibre cable is required and what reach can I expect?
A: This transceiver requires multi-mode fibre (MMF) with duplex LC connectors. It supports both 50/125um and 62.5/125um MMF. Reach up to 2km is achievable depending on fibre quality, connector loss, and link budget. For distances beyond 1.5km, verify your fibre plant attenuation is within the module's optical budget.

Q: How do I access the DOM diagnostic parameters?
A: DOM data is accessible via the two-wire serial interface defined in SFF-8472. Most Dell switches expose these parameters through their CLI or SNMP management interface. You can monitor transceiver temperature, transmit and receive optical power, laser bias current, and supply voltage in real time for link health diagnostics.

Q: Can I mix this transceiver with 1000BASE-X gigabit SFPs in the same switch?
A: Yes, provided the switch supports both 100 Mbps and 1 Gbps operation on its SFP ports. Many Dell switches auto-negotiate or require per-port speed configuration. Check your switch documentation to confirm mixed-speed SFP support and whether manual speed configuration is required for 100BASE-FX ports.
