• PAN-SFP-PLUS-LR-BCC white SFP+ transceiver with gold fiber connector
1 1

Blue Cable Co

PAN-SFP-PLUS-LR-BCC | Palo Alto Compatible 10GB Single-Mode 10km (10GBASE-LR)

PAN-SFP-PLUS-LR-BCC | Palo Alto Compatible 10GB Single-Mode 10km (10GBASE-LR)

PAN-SFP-PLUS-LR-BCC

In stock:51

$90.20 AUD
$90.20 AUD
$90.20 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The PAN-SFP-PLUS-LR-BCC is a drop-in compatible replacement for the Palo Alto PAN-SFP-PLUS-LR. This SFP+ transceiver provides plug-and-play connectivity for Palo Alto next-generation firewalls with SFP+ ports, enabling 10 Gigabit Ethernet over single-mode fibre. - 10GBASE-LR standard compliance ensures IEEE 802.3ae compatibility across vendor platforms - SFP+ form factor supporting 10.3 Gbps data rate over single-mode fibre at 1310nm wavelength - Reaches up to 10km over OS2 single-mode fibre with duplex LC connector interface - Digital Diagnostics Monitoring (DOM) provides real-time visibility of optical power, temperature, bias current, and voltage - Compliant with SFF-8431 MSA and operates within commercial temperature range of 0 to 70 degrees C - Hot-pluggable design enables field installation without powering down the firewall

Features

• 10GBASE-LR and 10GFC 1200-SM-LL-L compliance guarantee interoperability with IEEE 802.3ae-compliant equipment and Fibre Channel over Ethernet applications at matched data rates
• 1310nm DFB laser transmitter and PIN photodiode receiver with -5.2 to +0.5 dBm transmit power and -10.3 to +0.5 dBm receive sensitivity provide robust optical link budget for diverse deployment scenarios
• SFF-8431 MSA compliance ensures mechanical and electrical interoperability across multi-vendor SFP+ slots without vendor lock-in
• DOM/DDM support exposes real-time operating parameters including transmit and receive optical power, module temperature, laser bias current, and supply voltage for proactive link monitoring and troubleshooting
• Hot-pluggable SFP+ design permits in-service installation and removal without disrupting adjacent interfaces or requiring system shutdown
• Commercial temperature range operation (0 to 70 degrees C) suits standard data centre and network operations centre environments
• Low power consumption (<1W typical) minimises thermal load per port, enabling higher port density deployments in chassis with shared airflow budgets

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we'll deliver a replacement part before you return the faulty itemminimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: PAN-SFP-PLUS-LR-BCC
Compatible Replacement For: PAN-SFP-PLUS-LR
Compatibility: Palo Alto compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10.3 Gbps (9.95 to 10.5 Gbps)
Standard: 10GBASE-LR, 1200-SM-LL-L (10GFC)
Wavelength: 1310nm
Fibre Type: Single-Mode (SMF)
Connector Type: Duplex LC
Max Reach: Up to 10km (per IEEE 802.3ae, subject to fibre quality and link budget)
DOM Support: Yes (Digital Diagnostics Monitoring)
Operating Temperature: 0 to 70 degrees C (commercial range)
Electrical Interface: SFF-8431 compliant
Power Consumption: <1W

FAQs

Q: Will this work in place of the PAN-SFP-PLUS-LR?
A: Yes. This transceiver is a direct replacement for the Palo Alto PAN-SFP-PLUS-LR. It provides identical 10GBASE-LR functionality at 10.3 Gbps over single-mode fibre with the same SFP+ form factor, 1310nm wavelength, and duplex LC interface. The module is plug-and-play compatible and initialises seamlessly in any firewall that accepts the original Palo Alto part.

Q: Which Palo Alto firewalls support this transceiver?
A: This transceiver works in any Palo Alto firewall with SFP+ ports that support 10GBASE-LR optics, including the PA-5000 Series, PA-5200 Series, PA-5400 Series, PA-7000 Series, PA-3000 Series, and PA-1400 Series models. Verify your firewall has SFP+ interface slots (not standard SFP) and runs PAN-OS firmware that supports 10G interfaces.

Q: What fibre type and distance is supported for a 10km link?
A: This transceiver requires OS2 single-mode fibre (9/125 micron) for the full 10km reach. The optical link budget provides -5.2 to +0.5 dBm transmit power and -10.3 to +0.5 dBm receive sensitivity. Actual distance depends on fibre attenuation (typically 0.4 dB/km at 1310nm for OS2), splice loss, connector quality, and any inline passive components. Clean LC connectors and quality patch cables are essential to achieving rated performance.

Q: How do I access DOM diagnostic data on a Palo Alto firewall?
A: Use the CLI command 'debug system interface-xcvr-info log' to view DOM parameters including laser bias current, transmit optical power, receive optical power, module temperature, and supply voltage. You can also use 'show system state filter sys.s1.pXX.phy' (replace XX with the port number) to confirm transceiver detection and basic parameters. DOM visibility requires PAN-OS support and the transceiver must be seated and initialised.

Q: Can this transceiver support both 10G Ethernet and Fibre Channel traffic?
A: Yes. This module complies with both 10GBASE-LR (10.3 Gbps Ethernet per IEEE 802.3ae) and 1200-SM-LL-L (10GFC Fibre Channel) standards. It operates across the 9.95 to 10.5 Gbps data rate range, allowing use in Fibre Channel over Ethernet (FCoE) or native 10GFC applications where the host platform supports the protocol. The electrical interface conforms to SFF-8431, which defines multi-protocol support for SFP+ modules.
