Moxa WK-71-01 | Wall-Mounting Kit for UC-3400A, 2 Plates, 5 M3 Screws

Authorised Moxa Partner

SKU:WK-71-01

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa WK-71-01 is a wall-mounting kit for installing UC-3400A Series Arm Cortex-A53 industrial computers on a wall or inside a cabinet. The kit includes two mounting plates and five M3 x 5 mm screws, giving you what you need to attach the plates to the computer in industrial deployments.

The UC-3400A ships with a DIN-rail kit attached by default, so the WK-71-01 is supplied separately for sites that need wall or cabinet mounting instead. Four additional screws are required to fasten the computer to the wall or cabinet surface and are not included in the kit.

Features

- Simplifies installation of UC-3400A computers on walls or cabinets in industrial environments
- Supplied separately from the UC-3400A, which ships with a DIN-rail kit attached by default
- Includes two mounting plates and five M3 x 5 mm screws

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x mounting plates, each 71 x 44.8 x 5.7 mm
- 5 x M3 x 5 mm screws included
- Compatible with UC-3400A Series Arm Cortex-A53 computers
- Recommended screw torque: 4.5 +/- 0.5 kgf-cm
- 4 additional screws required to fasten the computer to a wall or cabinet (M3 x 0.5P thread, pan head, length over 6 mm), not included

FAQs

Q: Which computers is the Moxa WK-71-01 compatible with?
A: It is designed for the UC-3400A Series Arm Cortex-A53 industrial computers.

Q: What is included in the WK-71-01 kit?
A: The kit includes two mounting plates, each 71 x 44.8 x 5.7 mm, and five M3 x 5 mm screws.

Q: Are the screws for fixing the computer to the wall included?
A: No. Four additional screws are needed to fasten the computer to a wall or cabinet. They should be M3 x 0.5P thread, pan head, with a length over 6 mm.

Q: What torque should be used for the screws?
A: The recommended screw torque is 4.5 +/- 0.5 kgf-cm.

Q: Does the UC-3400A come with this kit?
A: No. The UC-3400A ships with a DIN-rail kit attached by default, and the WK-71-01 wall-mounting kit is sold separately.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
