Moxa V3210-TL1-4L-CT-T | V3200 Fanless Embedded Computer, Celeron 6305E, 4 GbE, -40 to 70°C

Authorised Moxa Partner

SKU:V3210-TL1-4L-CT-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa V3210-TL1-4L-CT-T is a fanless x86 embedded computer built on an Intel Celeron 6305E processor, designed for railway onboard and wayside applications. It provides 4 Gigabit Ethernet ports, 4 serial ports, DI/DO, USB, HDMI and VGA outputs, and a built-in TPM 2.0 module. A conformal-coated board and a wide -40 to 70°C operating range suit it to harsh in-vehicle and trackside deployments.

This model ships with 16 GB of DDR4 memory and a 128 GB NVMe M.2 drive pre-installed, with two SODIMM slots, two 2.5-inch drive bays and an mPCIe slot for expansion. It runs from a 24 to 110 VDC power input and supports Windows 10 IoT Enterprise LTSC 2021 and Moxa Industrial Linux 3.

Features

- Designed for railway onboard and wayside applications (EN 50155 class)
- Fanless x86 design with wide -40 to 70°C operating range
- Conformal coating for protection in harsh environments
- Power isolation and multiple expansion slots for wireless
- Two 2.5-inch SSD/HDD slots plus M.2 slot for storage expansion
- Built-in TPM 2.0 for hardware-based security
- Moxa Industrial Linux 3 supported

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: Intel Celeron 6305E (2C/2T, 4M cache, 1.8 GHz)
- Memory: 16 GB DDR4 pre-installed, 2 x SODIMM DDR4 slots (64 GB max)
- Storage: 128 GB M.2 M-key 2280 NVMe pre-installed, 2 x 2.5-inch SSD/HDD slots
- Graphics: Intel UHD Graphics, 1 x HDMI, 1 x VGA
- Network: 4 x Gigabit Ethernet
- Serial: 4 serial ports
- I/O: 2 x DI, 2 x DO, 2 x USB, 1 x mPCIe slot
- Security: built-in TPM 2.0 module
- Power input: 24 to 110 VDC
- Operating temperature: -40 to 70°C
- Conformal coating: yes
- OS support: Windows 10 IoT Enterprise LTSC 2021, Moxa Industrial Linux 3 (Debian 11), Linux drivers for Debian 12 and Ubuntu 22.04 LTS (HWE)

FAQs

Q: What processor does the Moxa V3210-TL1-4L-CT-T use?
A: It uses an Intel Celeron 6305E processor with 2 cores, 2 threads, 4M cache and a 1.8 GHz clock speed.

Q: What operating systems are supported?
A: It supports Windows 10 IoT Enterprise LTSC 2021 and Moxa Industrial Linux 3 (Debian 11). Linux drivers are also available for Debian 12 and Ubuntu 22.04 LTS (HWE).

Q: Is the board conformal coated and what temperature range does it support?
A: Yes, this model has a conformal-coated board and is rated for an operating temperature of -40 to 70°C.

Q: How much memory and storage is included, and can it be expanded?
A: It includes 16 GB DDR4 and a 128 GB NVMe M.2 drive. Memory can be expanded to 64 GB via 2 SODIMM slots, and two 2.5-inch SSD/HDD slots provide additional storage.

Q: What power input does it accept?
A: It accepts a 24 to 110 VDC power input.

Q: Which display outputs and network ports are available?
A: It provides 1 x HDMI and 1 x VGA output, plus 4 x Gigabit Ethernet ports.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
