Description

The Moxa V3200-WLAN22-AC is a Wi-Fi 5 (802.11ac) mPCIe module kit designed for Moxa V3200 Series railway x86 computers. It adds wireless connectivity to the host computer through its mPCIe slot, and ships with two 160 mm I-PEX MHF to QMA coaxial cables so external antennas can be connected straight away.

The kit also includes an mPCIe adapter bracket with screws and a thermal pad, giving integrators the parts needed to fit the module inside the computer. It suits rolling stock and rail-side deployments where V3200 computers, which are EN 50155 and EN 50121-4 compliant and IEC 61373 certified, need dependable wireless connectivity.

Features

- Adds Wi-Fi 5 wireless connectivity to V3200 Series railway computers
- QMA antenna connector cabling included for external antenna connection
- Complete kit with adapter bracket, screws and thermal pad for installation
- V3200 host computers are EN 50155 and EN 50121-4 compliant, and IEC 61373 certified for shock and vibration resistance

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 5 (802.11ac) wireless module
- Form factor: mPCIe (fits the V3200 mPCIe slot)
- 1 x mPCIe adapter bracket with 4 screws
- 2 x coaxial cables, I-PEX MHF male to QMA female, 160 mm
- 1 x thermal pad
- Compatible with Moxa V3200 Series computers

FAQs

Q: Which computers is the V3200-WLAN22-AC compatible with?
A: It is designed for Moxa V3200 Series x86 railway computers, using the mPCIe slot.

Q: What wireless standard does this module support?
A: It is a Wi-Fi 5 (802.11ac) module.

Q: What is included in the kit?
A: The kit includes the Wi-Fi module, an mPCIe adapter bracket with 4 screws, two 160 mm I-PEX MHF male to QMA female coaxial cables and a thermal pad.

Q: Are antennas included?
A: No. The kit includes QMA-terminated coaxial cables so you can connect external antennas, which are sold separately.

Q: Can the mPCIe slot be used for other expansion options?
A: Yes. The V3200 mPCIe slot supports Wi-Fi 5, LTE or I/O expansion, so this kit is one of several options for that slot.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
