Moxa V1200 Desk-mounting Kit | 2 Plates, 4x M3 x 5mm Screws

Authorised Moxa Partner

SKU:V1200 Desk-mounting Kit

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The V1200 Desk-mounting Kit is an optional mounting accessory for Moxa V1200 Series industrial Arm computers. It lets the V1200 sit on a desk or bench instead of using the standard wall-mounting kit that ships with the computer. The kit includes 2 mounting plates (44.8 x 99 x 5.7 mm each) and 4 x M3 x 5 mm screws.

It suits the V1200 Series models V1202-CT-T, V1222-CT-T and V1222-W-CT-T. The kit is sold separately from the V1200 computer. Additional M3 x 6 mm screws, which are not included, are needed to attach the plates to the V1200 unit.

Features

- Enables desk mounting of the V1200 Series, which ships with a wall-mounting kit as standard
- Optional accessory sold separately from the V1200 computer
- Includes 2 mounting plates and 4 x M3 x 5 mm screws
- Additional M3 x 6 mm screws, not included, are needed to attach the plates to the V1200 unit

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Product type: Desk-mounting kit for V1200 Series
- Plates: 2 x mounting plates
- Plate dimensions (H x W x D): 44.8 x 99 x 5.7 mm each
- Screws included: 4 x M3 x 5 mm
- Compatible series: V1200 Series (V1202-CT-T, V1222-CT-T, V1222-W-CT-T)
- Installation method enabled: Desk mounting

FAQs

Q: Which Moxa computers does this desk-mounting kit suit?
A: It is designed for the Moxa V1200 Series, including the V1202-CT-T, V1222-CT-T and V1222-W-CT-T models.

Q: What is included in the kit?
A: The kit contains 2 mounting plates (44.8 x 99 x 5.7 mm each) and 4 x M3 x 5 mm screws.

Q: Does the V1200 computer come with this kit?
A: No. The V1200 Series ships with a wall-mounting kit as standard. The desk-mounting kit is an optional accessory sold separately.

Q: Do I need extra screws to attach the plates to the V1200?
A: Yes. Additional M3 x 6 mm screws, which are not included, are needed to attach the plates to the V1200 unit.

Q: Can I use this kit for wall mounting?
A: No. This kit enables desk mounting. The standard wall-mounting kit supplied with the V1200 is used for wall installations.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
