Moxa V1200-5G | V1200 5G Cellular Module Kit, Telit FN990A28W

Authorised Moxa Partner

SKU:V1200-5G

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa V1200-5G is a 5G cellular module kit for the V1200 Series of fanless, railway-grade Arm-based computers. It is built around a Telit FN990A28W sub-6 GHz module supporting both NSA and SA modes, and installs in the M.2 B-key (5G) slot of compatible V1200 computers to add high-speed cellular connectivity to rolling stock and other rugged field deployments.

The kit includes five IPEX MHF4 to QMA coaxial cables (four for cellular data and one for GNSS), a heat sink and two thermal pads, so everything needed for installation is supplied. The module falls back to LTE and UMTS/HSPA bands where 5G coverage is unavailable, and supports GPS, GLONASS, BeiDou and Galileo positioning with active or passive antennas. Note that 5G and LTE cannot be operated at the same time.

Features

- Adds 5G connectivity to compatible V1200 Series computers
- LTE and UMTS/HSPA fallback bands for wide network compatibility
- Integrated GNSS support with active or passive antennas
- Supplied with the cables, thermal pads and heat sink needed for installation
- Host computers are fanless and railway-certified to EN 50155
- Host computers are covered by a 5-year warranty and 10-year Moxa Industrial Linux support

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Telit FN990A28W 5G sub-6 GHz module, NSA and SA
- Installs in the M.2 B-key (5G) slot of V1200 Series computers
- 5 x IPEX MHF4 to QMA coaxial cables (4 for cellular data, 1 for GNSS)
- 2 x thermal pads and 1 x heat sink included
- 5G NR bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n77, n78, n79
- LTE bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
- UMTS/HSPA bands: 1, 2, 4, 5, 6, 8, 19
- Nano SIM format, 2 SIMs for 5G on V1222-CT-T and V1222-W-CT-T
- GNSS: GPS, GLONASS, BeiDou, Galileo, wide-band 1559 to 1606 MHz
- GNSS antenna: active (default) or passive 1.5 to 3 dBi, 1 Hz minimum update rate
- GNSS time to first fix: hot 1 s, warm 27 s, cold 28 s
- GNSS sensitivity: cold start -146 dBm, tracking -161 dBm, acquisition -148 dBm
- Host operating temperature (with cellular and Wi-Fi): -40 to 70 C
- Host certifications: CE, FCC, UKCA, EN 50155:2021, EN 50121-4, IEC 62368-1

FAQs

Q: Which Moxa computers is the V1200-5G compatible with?
A: It is designed for the V1200 Series and installs in the M.2 B-key (5G) slot. SIM and antenna details are specified for the V1222-CT-T and V1222-W-CT-T models.

Q: What is included in the kit?
A: The kit contains a Telit FN990A28W 5G module, five IPEX MHF4 to QMA coaxial cables, two thermal pads and one heat sink.

Q: Can 5G and LTE be used at the same time?
A: No. 5G and LTE cannot be operated simultaneously on this module.

Q: Does the module support GNSS positioning?
A: Yes. It supports GPS, GLONASS, BeiDou and Galileo. One of the five supplied cables is dedicated to GNSS, and either active (default) or passive antennas can be used.

Q: How many antennas and SIMs are needed?
A: Four cellular antennas connect via the QMA connectors on the host, plus one GNSS antenna. The module uses Nano SIMs, with two SIM slots available for 5G on the V1222-CT-T and V1222-W-CT-T.

Q: Will it fall back to older networks if 5G is unavailable?
A: Yes. The module supports LTE and UMTS/HSPA bands in addition to 5G NR NSA and SA, so it can fall back where 5G coverage is not available.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
