Description

The RKP-C220-C9-4L-T is a fanless 2U industrial rackmount PC built on a 13th Gen Intel Core i9-13900TE processor and Intel Q670E chipset. This model has 8 LAN ports, 2 serial ports and 4 DI/4 DO, with 8 GB DDR4 pre-installed and a 100 to 240 VAC power input. It is rated for -30 to 60°C operation, making it suited to factory automation, transport and other demanding edge computing deployments.

Expansion includes 3 PCIe slots, with the x16 slot supporting an NVIDIA RTX Series FLFH GPU card up to 200 W TDP. Storage options cover 2 lockable 2.5-inch SATA SSD slots and M.2 M key slots, with Intel RST RAID 0/1 support. Video output is provided by HDMI 2.0b and DisplayPort 1.2, and the system includes a built-in TPM 2.0 module and supports Windows 11 IoT Enterprise LTSC 2024, Windows Server 2022, Debian 12, Ubuntu 22.04 LTS and RHEL 9.0.

Features

- 13th Gen Intel Core Raptor Lake-S processor with Intel Q670E chipset for demanding industrial workloads
- Fanless 2U rackmount design for reliable, low-maintenance operation
- Supports NVIDIA RTX Series FLFH GPU card up to 200 W TDP for edge AI and vision applications
- 3 PCIe slots for flexible expansion
- 2 lockable 2.5-inch SATA SSD slots and extendable M.2 M key SSD slots supporting 2 sets of Intel RST RAID 0/1
- Wide -30 to 60°C operating temperature range
- Built-in TPM 2.0 module for hardware-based security
- Built-in watchdog timer for automatic reboot and RTC with lithium-battery backup
- Optional additional fan module to increase performance

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: Intel Core i9-13900TE
- Chipset: Intel Q670E
- Memory: 8 GB DDR4 pre-installed, 2 x SODIMM DDR4 slots, up to 64 GB
- Graphics: Intel UHD Graphics 770
- Video output: 1 x HDMI 2.0b, 1 x DisplayPort 1.2
- LAN ports: 8
- Serial ports: 2 x DB9 male, 50 bps to 115.2 kbps
- Digital I/O: 4 x DI (dry contact), 4 x DO (sink type), spring-type Euroblock terminal
- USB: 3 x USB 3.0 external type-A, 1 x USB 3.0 internal type-A
- Storage: 2 x 2.5-inch SATA III SSD slots (RAID 0/1), 1 x M.2 M key 2280 (PCIe, NVMe), 2 x M.2 M key 2242
- Expansion: 3 PCIe slots (x16, x8 with 4 lanes, x1)
- Power input: 100 to 240 VAC
- Operating temperature: -30 to 60°C
- Mounting: standard 2U rack mount
- Weight: 8,914 g (19.65 lb)
- MTBF: 1,101,194 hrs
- Certifications: RoHS, CRoHS, WEEE

FAQs

Q: What processor and memory does the RKP-C220-C9-4L-T include?
A: It uses an Intel Core i9-13900TE processor with an Intel Q670E chipset and ships with 8 GB DDR4 pre-installed. The two SODIMM DDR4 slots support up to 64 GB.

Q: Can I install a GPU in this computer?
A: Yes. The x16 PCIe slot supports an NVIDIA RTX Series FLFH GPU card with up to 200 W TDP.

Q: What operating systems are supported?
A: Supported operating systems include Windows 11 IoT Enterprise LTSC 2024 64-bit, Windows 11 Professional 64-bit, Windows Server 2022, Debian 12, Ubuntu 22.04 LTS and RHEL 9.0.

Q: What I/O does this 4L model provide?
A: It has 8 LAN ports, 2 DB9 serial ports, 4 digital inputs, 4 digital outputs, 3 external USB 3.0 ports, HDMI 2.0b and DisplayPort 1.2 video outputs.

Q: What storage options and RAID support are available?
A: There are 2 lockable 2.5-inch SATA III SSD slots with RAID 0/1 support, plus M.2 M key slots including one 2280 PCIe NVMe socket. Intel RST RAID 0/1 is supported.

Q: What power input and temperature range does it support?
A: It accepts 100 to 240 VAC power input and is rated for operation from -30 to 60°C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
