Moxa RKP-C110-C7-2HV-T | RKP-C110 1U Industrial Computer, Core i7, 8 DI/8 DO

Authorised Moxa Partner

SKU:RKP-C110-C7-2HV-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa RKP-C110-C7-2HV-T is a 1U rackmount industrial computer built on an 11th-gen Intel Core i7-1185G7E processor with Intel Iris Xe graphics. It combines 4 Gigabit LAN ports, 2 software-selectable RS-232/422/485 serial ports, 8 digital inputs and 8 digital outputs, making it well suited to industrial automation, machine control and edge computing deployments in racks and cabinets. The 2HV-T variant accepts a 100 to 240 VAC/VDC input and operates across a -30 to 60°C temperature range.

The system ships with 8 GB of DDR4 memory and one SODIMM slot expandable to 32 GB, plus dual 2.5-inch SATA III SSD bays with RAID 0/1 support for storage redundancy or performance. Three USB 3.0 ports, HDMI 2.0b and VGA outputs, TPM v2.0 and a metal housing complete the package, with Windows 10 IoT Enterprise LTSC 2021, Windows 11 IoT Enterprise LTSC 2024 and Debian 11 images supported.

Features

- 11th-gen Intel Core i7-1185G7E processor with Intel Iris Xe graphics for demanding industrial workloads
- Dual 2.5-inch SATA SSD bays with RAID 0/1 support
- Wide-range 100 to 240 VAC/VDC power input on the 2HV-T model
- Extended -30 to 60°C operating temperature range
- 8 DI and 8 DO on spring-type Euroblock terminals for direct field wiring
- 4 Gigabit LAN ports with 1.5 kV built-in magnetic isolation protection
- TPM v2.0 for hardware-based security
- Supports Windows 11 IoT Enterprise LTSC 2024, Windows 10 IoT Enterprise LTSC 2021 and Debian 11 images
- Built-in watchdog timer and RTC with lithium-battery backup
- Standard 1U rackmount with metal housing

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Processor: Intel Core i7-1185G7E, quad core, 12M cache, up to 2.80 GHz, base 1.80 GHz
- Graphics: Intel Iris Xe Graphics
- Memory: 8 GB DDR4 pre-installed, 1 x SODIMM slot, up to 32 GB
- Storage: 2 x 2.5-inch SATA III SSD slots, RAID 0/1 support
- Ethernet: 4 x auto-sensing 10/100/1000 Mbps RJ45 ports
- Serial: 2 x RS-232/422/485, software selectable, DB9 male, 50 bps to 115.2 kbps
- Digital I/O: 8 x DI (dry contact), 8 x DO (sink type, 200 mA per channel, 0 to 24 VDC), spring-type Euroblock terminals
- USB: 3 x USB 3.0 Type-A
- Video output: 1 x HDMI 2.0b, 1 x VGA (15-pin D-sub female)
- Security: TPM v2.0
- Power input: 100 to 240 VAC/VDC, screw-fastened Euroblock terminal
- Power consumption: 90 W
- Operating temperature: -30 to 60°C (-22 to 140°F)
- Storage temperature: -40 to 75°C (-40 to 167°F)
- Humidity: 5 to 95% non-condensing
- Housing: metal, IP20
- Dimensions: 440 x 360 x 43.65 mm (17.32 x 14.17 x 1.72 in)
- Weight: 5,616 g (12.38 lb)
- Mounting: standard 1U rackmount
- Safety and EMC: IEC 62368-1, UL 62368-1, BSMI, EN 55032/35, CISPR 32, FCC Part 15B Class A
- MTBF: 1,435,365 hrs (Telcordia, GB)

FAQs

Q: What operating systems does the RKP-C110-C7-2HV-T support?
A: It supports Windows 11 IoT Enterprise LTSC 2024, Windows 10 IoT Enterprise LTSC 2021 and Debian 11 images.

Q: How much memory can be installed?
A: The unit comes with 8 GB of DDR4 pre-installed and has one SODIMM slot, with a maximum of 32 GB supported.

Q: Does it support storage redundancy?
A: Yes. It has two 2.5-inch SATA III SSD bays with RAID 0 and RAID 1 support, so you can configure striping for speed or mirroring for redundancy.

Q: What power input does the 2HV-T model accept?
A: The 2HV-T model accepts 100 to 240 VAC/VDC through a screw-fastened Euroblock terminal, so it works with both AC and DC supplies.

Q: What operating temperature range does it cover?
A: The RKP-C110-C7-2HV-T operates from -30 to 60°C (-22 to 140°F), suited to unconditioned cabinets and harsh industrial sites.

Q: What I/O and display connections are available?
A: It provides 8 digital inputs, 8 digital outputs, 2 RS-232/422/485 serial ports, 4 Gigabit LAN ports and 3 USB 3.0 ports, with HDMI 2.0b and VGA for video output.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
