Moxa RKP-C110-C1-2HV-T | RKP-C110 1U Industrial Computer, Celeron 6305E, 4 LAN, 2 Serial

Authorised Moxa Partner

SKU:RKP-C110-C1-2HV-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa RKP-C110-C1-2HV-T is a fanless 1U rackmount industrial computer built on an 11th Gen Intel Celeron 6305E processor. It offers 4 LAN ports, 2 software-selectable RS-232/422/485 serial ports, 8 digital inputs and 8 digital outputs, making it a strong fit for edge computing, automation and data acquisition in control cabinets and racks. This 2HV model accepts a 100 to 240 VAC/VDC power input, and the -T variant is rated for -30 to 60°C operation.

The system ships with 8 GB DDR4 pre-installed, with one SODIMM slot supporting up to 32 GB. Two 2.5-inch SATAIII SSD bays support RAID 0/1, and video is provided through HDMI 2.0b and VGA outputs. Three USB 3.0 Type-A ports, a built-in TPM v2.0 module and unified front-panel connectivity simplify deployment, while the metal housing and wide temperature range suit demanding industrial sites.

Features

- Fanless 1U rackmount design for quiet, reliable operation
- 11th Gen Intel Celeron 6305E processor for edge computing and automation workloads
- 4 LAN ports and 2 software-selectable RS-232/422/485 serial ports for flexible connectivity
- 8 digital inputs and 8 digital outputs for direct control and monitoring of field devices
- 100 to 240 VAC/VDC wide-range power input (2HV model)
- 30 to 60°C wide operating temperature range (-T model)
- Two hand-rotated 2.5-inch SSD bays with RAID 0/1 support
- Externally replaceable RTC battery for simpler maintenance
- Built-in TPM 2.0 module for hardware-based security
- Unified front-panel connectivity for easy access to interfaces

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Processor: Intel Celeron 6305E, dual core, 4M cache, 1.80 GHz
- Memory: 8 GB DDR4 pre-installed, 1 x SODIMM slot, up to 32 GB
- Storage: 2 x 2.5-inch SATAIII SSD slots with RAID 0/1 support
- Network: 4 x LAN ports with 1.5 kV built-in magnetic isolation
- Serial: 2 x software-selectable RS-232/422/485, DB9 male, 50 bps to 115.2 kbps
- Digital I/O: 8 x DI (dry contact), 8 x DO (sink type, 200 mA per channel, 0 to 24 VDC)
- USB: 3 x USB 3.0 Type-A
- Video: 1 x HDMI 2.0b, 1 x VGA (15-pin D-sub female)
- Security: TPM v2.0
- Power input: 100 to 240 VAC/VDC, screw-fastened Euroblock terminal
- Power consumption: 90 W
- Operating temperature: -30 to 60°C
- Housing: Metal, IP20
- Dimensions: 440 x 360 x 43.65 mm
- Weight: 5,616 g
- MTBF: 1,435,365 hrs
- Safety: UL 62368-1 (CB), BSMI

FAQs

Q: What does the 2HV in RKP-C110-C1-2HV-T mean?
A: It denotes the power input version. This model accepts 100 to 240 VAC/VDC through a screw-fastened Euroblock terminal.

Q: What does the -T suffix indicate?
A: The -T suffix is the wide temperature version, rated for operation from -30 to 60°C.

Q: How much memory and storage does it support?
A: It ships with 8 GB DDR4 pre-installed, with one SODIMM slot supporting up to 32 GB. Two 2.5-inch SATAIII SSD slots support RAID 0/1.

Q: What serial and I/O interfaces are included?
A: It has 2 software-selectable RS-232/422/485 serial ports on DB9 male connectors, plus 8 digital inputs and 8 digital outputs on spring-type Euroblock terminals.

Q: Does this model have a cooling fan?
A: No. The RKP-C110 series uses a fanless design, which suits dusty or vibration-prone industrial environments.

Q: Is rack-mounting hardware included?
A: Yes. The package includes the computer with rack-mounting ears, two 10-pin terminal blocks for the DI/DOs and a terminal block for power.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
