Moxa MPC-3120-E2-LB-T | MPC-3120 12.1in Fanless Panel PC, Atom x6211E, 8GB, 400-nit, -T

Authorised Moxa Partner

SKU:MPC-3120-E2-LB-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa MPC-3120-E2-LB-T is a 12.1-inch fanless industrial panel PC built around a dual-core Intel Atom x6211E processor with 8 GB DDR4 memory. It features a 4:3 XGA (1024 x 768) 400-nit LCD with glove-friendly projective capacitive multi-touch and an IP66-rated front panel, and the -T wide temperature design operates from -30 to 60°C with no heater required, suiting harsh, hot and outdoor deployments such as oil and gas fields and drilling platforms.

I/O includes two Gigabit Ethernet ports with native network redundancy, two software-selectable RS-232/422/485 serial ports, two USB 3.0 ports, four isolated digital inputs and four isolated digital outputs, plus HDMI output for an external display. Storage is expandable via CFast and SD 3.0 slots, TPM v2.0 is onboard, and the unit runs from a 12/24 VDC supply. It supports Windows 10 IoT Enterprise LTSC 2021, Windows 11 Professional, Debian 11, Ubuntu 22.04 LTS and RHEL 9.

Features

- Fanless design with no heater required, rated -30 to 60°C
- Sunlight-readable 400-nit LCD
- Glove-friendly PCAP multi-touch screen
- IP66-rated front panel for dust and water ingress protection
- Two Gigabit Ethernet ports with native network redundancy
- Two software-selectable RS-232/422/485 serial ports
- 12/24 VDC power input
- Hazardous location and maritime certifications including ATEX Zone 2, Class I Division 2, IECEx and DNV (certification processes still underway)
- Suited to harsh, hot, outdoor environments such as oil and gas fields and drilling platforms

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 12.1-inch 4:3 XGA (1024 x 768) AAS panel, 400 nits, 1000:1 contrast, 178°/178° viewing angles
- Projective capacitive touchscreen, 4 touch points, glove support
- Intel Atom Elkhart Lake x6211E dual-core 1.30 GHz with Intel UHD Graphics
- 8 GB DDR4 2400 MHz pre-installed, 1 x SODIMM slot, 32 GB maximum
- 2 x 10/100/1000 Mbps Ethernet (RJ45) with 1.5 kV magnetic isolation
- 2 x RS-232/422/485 serial ports (DB9 male, software-selectable), 50 bps to 115.2 kbps
- 2 x USB 3.0 type-A
- 4 x isolated DI and 4 x isolated DO
- 1 x HDMI 1.2a video output
- 1 x CFast slot and 1 x SD 3.0 slot (SDHC/SDXC)
- TPM v2.0
- 12/24 VDC input, 48 W maximum power consumption
- IP66 front, IP20 rear, metal housing
- Dimensions: 315 x 220 x 75.7 mm, weight 2,900 g
- Operating temperature -30 to 60°C, humidity 5 to 95% non-condensing
- Approvals include ATEX Zone 2, Class I Division 2, IECEx Zone 2, DNV-CG-0339, IEC 60945, IACS E10

FAQs

Q: Which operating systems does the MPC-3120-E2-LB-T support?
A: It supports Windows 10 IoT Enterprise LTSC 2021, Windows 11 Professional (64-bit), Debian 11 (kernel 5.10), Ubuntu 22.04 LTS and RHEL 9 (kernel 5.14).

Q: What does the LB and -T suffix mean?
A: LB denotes the 400-nit LCD, while -T denotes the wide operating temperature range of -30 to 60°C. This model has the dual-core Atom x6211E CPU and 8 GB RAM.

Q: Does it need a heater or fan for cold or hot environments?
A: No. It is fanless and rated -30 to 60°C with no heater required.

Q: Can I expand the memory and storage?
A: Yes. The single DDR4 SODIMM slot supports up to 32 GB, and storage can be added via the CFast slot and the SD 3.0 slot.

Q: Can it be used with gloves or in wet conditions?
A: Yes. The projective capacitive touchscreen supports glove operation and the front panel is rated IP66.

Q: What power supply does it use?
A: It runs from a 12/24 VDC input, with maximum power consumption of 48 W including full USB loading.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
