• Moxa ISD-1110-T black USB-to-VGA adapter with short cable, blue VGA connector
1 1

Moxa

Moxa ISD-1110-T | RS-232 Serial Surge Protector, 7-Line, DB9 Male, 4 kV

Moxa ISD-1110-T | RS-232 Serial Surge Protector, 7-Line, DB9 Male, 4 kV

Authorised Moxa Partner

ISD-1110-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa ISD-1110-T is a 7 data line RS-232 serial surge protector with a DB9 male connector, designed to shield modems, terminals, I/O ports and instrumentation from damaging voltage surges. It provides 4 kV surge protection to IEC 61000-4-5 for serial signal lines and supports baud rates from 50 bps to 921.6 kbps.

Built for demanding industrial sites, the ISD-1110-T operates across a wide -40 to 85°C temperature range in a compact plastic IP30 housing measuring 53 x 37 x 20.6 mm. Plug and play desktop installation makes it a simple way to harden existing RS-232 links against transient surges.

Features

- Plug and play
- EN 61000-4-5 Level 4 surge protection for serial data lines
- Compact size for easy installation
- Wide-temperature design for -40 to 85°C environments

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 7 data line entry surge protector
- RS-232 serial standard
- DB9 male connector
- 4 kV surge protection (IEC 61000-4-5, signal)
- Baudrate: 50 bps to 921.6 kbps
- Operating temperature: -40 to 85°C (-40 to 185°F)
- Storage temperature: -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- Housing: plastic, IP30
- Dimensions: 53 x 37 x 20.6 mm
- Weight: 58 g (product only), 119 g (packaged)
- Desktop installation
- Safety: EN 60950-1, IEC 60950-1

FAQs

Q: What serial standard does the ISD-1110-T protect?
A: It protects RS-232 serial data lines and uses a DB9 male connector.

Q: What level of surge protection does it provide?
A: It provides 4 kV surge protection on signal lines, in line with IEC 61000-4-5 (EN 61000-4-5 Level 4).

Q: What baud rates does it support?
A: It supports baud rates from 50 bps up to 921.6 kbps.

Q: Can it be used in extreme temperatures?
A: Yes. It has an operating temperature range of -40 to 85°C (-40 to 185°F).

Q: How is the ISD-1110-T installed?
A: It is a plug and play device intended for desktop installation, with a compact 53 x 37 x 20.6 mm plastic IP30 housing.

Q: What devices is it suited to protecting?
A: It is suited to RS-232 connected equipment such as modems, terminals, I/O ports and instrumentation.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
