• Moxa EDR-G9004-VPN-2MGTXSFP/KC black switch with teal Siemens logo
1 1

Moxa

Moxa EDR-G9004-VPN-2MGTXSFP/KC | EDR-G9004 Industrial Secure Router, 2x Bypass RJ45, 2x SFP/RJ45, KC

Moxa EDR-G9004-VPN-2MGTXSFP/KC | EDR-G9004 Industrial Secure Router, 2x Bypass RJ45, 2x SFP/RJ45, KC

Authorised Moxa Partner

EDR-G9004-VPN-2MGTXSFP/KC

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The EDR-G9004 Industrial Secure Router combines a firewall, NAT, IPsec VPN and routing in one DIN-rail unit built for industrial networks. This KC certified variant provides 2 x Gigabit RJ45 ports with Gen3 LAN Bypass plus 2 x Gigabit RJ45/SFP combo ports, with up to 2 Gbps routing and firewall throughput and up to 800 Mbps VPN throughput across a maximum of 250 IPsec tunnels. It operates from -10 to 60°C and does not carry conformal coating.

Deep packet inspection recognises industrial protocols including Modbus TCP/UDP, DNP3, IEC 60870-5-104, IEC 61850 MMS, EtherNet/IP, OPC UA and Siemens S7, allowing granular control over control-system traffic. Redundant dual 12/24/48 VDC inputs, a metal IP40 housing, Secure Boot and maritime, rail, substation and hazardous-location approvals make it suited to substations, transport, marine and factory automation deployments.

Features

- Integrated industrial firewall, NAT, IPsec VPN and router in one device
- Gen3 LAN Bypass on the two RJ45 ports
- Deep packet inspection for Modbus, DNP3, IEC 60870-5-104, IEC 61850 MMS, EtherNet/IP, OPC UA, Siemens S7 and more
- Optional Intrusion Prevention System with additional licence
- Secure Boot for firmware integrity
- Router firewall and transparent (bridge) firewall modes with DMZ support
- Redundant dual power inputs with reverse polarity protection
- Management via web console (HTTPS), SSH, SNMPv1/v2c/v3, LLDP and DHCP
- Maritime, rail, substation and hazardous-location certifications

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100/1000BaseT(X) RJ45 ports with Gen3 LAN Bypass
- 2 x combo ports (10/100/1000BaseT(X) or 1000/2500BaseSFP)
- Routing and firewall throughput: max. 2 Gbps (350K pps)
- IPS throughput: max. 2 Gbps (200K pps), IPS requires an additional licence
- IPsec VPN: max. 250 concurrent tunnels, max. 800 Mbps (AES-256, SHA-256)
- Max. 400K concurrent connections, 20K connections per second
- Routing table: max. 4K rules; OSPF, RIPv1/v2, static routing, VRRP
- Input voltage: 12/24/48 VDC, redundant dual inputs, reverse polarity protection
- Console: RS-232 and USB Type-C; reset button
- Metal housing, IP40, 45 x 135 x 105 mm, 800 g
- DIN-rail mounting, wall mounting with optional kit
- Operating temperature: -10 to 60°C; storage temperature: -40 to 85°C
- Humidity: 5 to 95% non-condensing
- Approvals: IEC 62368-1, EN 50121-4, IEC 61850-3 Ed. 2.0, IEEE 1613, DNV, ATEX, Class I Division 2, IECEx
- MTBF: 1,876,185 hours

FAQs

Q: What does this KC variant offer compared with other EDR-G9004 models?
A: This model has 2 x RJ45 ports with Gen3 LAN Bypass and 2 x RJ45/SFP combo ports, operates from -10 to 60°C and has no conformal coating. It is the KC certified version of the range.

Q: Does it support SFP modules?
A: Yes. The two combo ports accept either 10/100/1000BaseT(X) copper connections or 1000/2500BaseSFP fibre modules.

Q: How many VPN tunnels does it support?
A: It supports up to 250 concurrent IPsec VPN tunnels, with throughput of up to 800 Mbps using AES-256 and SHA-256.

Q: Is the Intrusion Prevention System included?
A: No. The IPS function requires an additional licence. Firewall, NAT, VPN and deep packet inspection are available on the device.

Q: What power input does it need?
A: It runs from 12, 24 or 48 VDC with redundant dual inputs via a removable terminal block, and has reverse polarity protection.

Q: How is it mounted?
A: It mounts on a DIN rail as standard, and wall mounting is possible with the optional kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
