Moxa DE-PRP-HSR-EF | DA-720 PCIe PRP/HSR LAN Module, 2-Port 100/1000 Mbps, RJ45 + SFP

Authorised Moxa Partner

SKU:DE-PRP-HSR-EF

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa DE-PRP-HSR-EF is a PCIe PRP/HSR LAN expansion module for Moxa DA-720 Series industrial computers, providing two 100/1000 Mbps ports with RJ45 and SFP connectivity. It complies with IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR), delivering zero-recovery-time redundancy for mission-critical networks such as power substation automation and process automation.

The dual Gigabit Ethernet port design supports high-performance redundant communication, with 1.5 kV built-in magnetic isolation protection. With an operating temperature range of -25 to 55°C, it is suited to demanding industrial deployments where network availability cannot be compromised.

Features

- Complies with IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR)
- Redundancy with zero-time recovery for mission-critical applications
- Dual Gigabit Ethernet port design for high performance
- Designed for Moxa DA-720 Series industrial computers
- Suited to power substation automation and process automation systems

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100/1000BaseT(X) RJ45 ports
- 2 x 1000BaseSFP slots
- Speed: 100/1000 Mbps
- PRP/HSR support (IEC 62439-3 Clause 4 and 5)
- Magnetic isolation protection: 1.5 kV (built-in)
- Dimensions: 213.31 x 95 mm (8.398 x 3.74 in)
- Weight: 365 g (0.80 lb)
- Operating temperature: -25 to 55°C (-13 to 131°F)
- Storage temperature (package included): -40 to 85°C (-40 to 185°F)
- MTBF: 1,895,911 hrs (Telcordia (Bellcore), GB)
- Green product: RoHS, CRoHS, WEEE
- Package contents: 1 x DA-720-Ethernet Series expansion module, 1 x warranty card

FAQs

Q: Which computers is the DE-PRP-HSR-EF designed for?
A: It is an expansion module for Moxa DA-720 Series industrial computers.

Q: Which redundancy protocols does it support?
A: It supports PRP and HSR, complying with IEC 62439-3 Clause 4 and Clause 5, providing zero-recovery-time redundancy.

Q: What port types are provided?
A: The module provides 2 x 10/100/1000BaseT(X) RJ45 ports and 2 x 1000BaseSFP slots.

Q: What applications is it suited to?
A: It is suited to power substation automation and process automation systems that require zero-recovery-time redundant networking.

Q: What is the operating temperature range?
A: The module operates from -25 to 55°C (-13 to 131°F).

Q: Does the module include electrical isolation?
A: Yes, it has built-in 1.5 kV magnetic isolation protection.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
