Moxa DE-LN08-RJ | DA-720 8-Port RJ45 Gigabit PCIe LAN Module

Authorised Moxa Partner

SKU:DE-LN08-RJ

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa DE-LN08-RJ is an 8-port RJ45 Gigabit PCIe LAN module designed to expand network connectivity on Moxa DA-720 series industrial rackmount computers. Each of the eight 10/100/1000BaseT(X) ports uses a standard RJ45 connector, making it well suited to edge and substation deployments that need many isolated network segments from a single computer.

Built-in 1.5 kV magnetic isolation protects each port, and the module operates across a wide -25 to 55°C temperature range for demanding industrial environments. It belongs to the DA-720-Ethernet expansion family, which also includes the 4-port DE-LN04-RJ and the DE-PRP-HSR-EF PRP/HSR module.

Features

- 8-port Gigabit LAN module for PCIe expansion slots on the DA-720 series
- Wide operating temperature range of -25 to 55°C
- Built-in 1.5 kV magnetic isolation protection
- Part of the DA-720-Ethernet family alongside the 4-port DE-LN04-RJ and PRP/HSR DE-PRP-HSR-EF modules

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x 10/100/1000BaseT(X) RJ45 ports
- Magnetic isolation protection: 1.5 kV (built-in)
- Dimensions: 213.31 x 95 mm (8.398 x 3.74 in)
- Weight: 365 g (0.80 lb)
- Operating temperature: -25 to 55°C (-13 to 131°F)
- Storage temperature (package included): -40 to 85°C (-40 to 185°F)
- MTBF: 1,459,164 hrs (Telcordia)
- Green product: RoHS, CRoHS, WEEE
- Package contents: 1 x DA-720-Ethernet Series expansion module, 1 x warranty card

FAQs

Q: Which computers is the Moxa DE-LN08-RJ designed for?
A: It is an expansion module for the Moxa DA-720 series industrial rackmount computers, installed in the PCIe expansion slot.

Q: How many network ports does the DE-LN08-RJ add?
A: It adds eight 10/100/1000BaseT(X) ports with RJ45 connectors.

Q: Does the module include electrical isolation?
A: Yes, it has built-in 1.5 kV magnetic isolation protection on its Ethernet ports.

Q: What operating temperature range does it support?
A: The module operates from -25 to 55°C, suitable for industrial environments.

Q: How does it differ from the DE-LN04-RJ?
A: Both are RJ45 Gigabit modules in the DA-720-Ethernet family. The DE-LN08-RJ provides eight ports, while the DE-LN04-RJ provides four.

Q: Does it support PRP/HSR redundancy?
A: No. The DE-LN08-RJ is a standard Gigabit LAN module. PRP/HSR is provided by the separate DE-PRP-HSR-EF module in the same family.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
