Moxa DE-FX02-SFP-T | DA-820 Ethernet Expansion Module, 2-Port 100 Mbps SFP, PCIe

Authorised Moxa Partner

SKU:DE-FX02-SFP-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa DE-FX02-SFP-T is a 2-port 100 Mbps SFP fibre Ethernet expansion card with a PCIe interface, designed for Moxa DA-820 series x86 industrial computers. It adds fibre network connectivity to the host system for industrial communication with Ethernet-based devices, and is the 100 Mbps option in the range (the DA-GX02-SFP-T sibling is 1000 Mbps).

Built with a wide-temperature design for industrial environments, the module is rated for operation from -40 to 70°C. SFP transceivers are not included and must be selected to suit your fibre type and link distance. The module is RoHS, CRoHS and WEEE compliant and carries an MTBF of 1,403,659 hours.

Features

- 2-port 100 Mbps SFP fibre connectivity (SFP modules excluded)
- PCIe expansion module for the DA-820 series
- Suited to industrial communication with Ethernet-based devices
- Wide-temperature design for industrial environments
- Flexible fibre type and reach through your choice of SFP transceiver

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Ports: 2 x SFP fibre (SFP modules not included)
- Speed: 100 Mbps
- Interface: PCIe
- Compatibility: Moxa DA-820 series x86 computers
- Operating temperature: -40 to 70°C (-40 to 158°F)
- Storage temperature (package included): -40 to 85°C (-40 to 185°F)
- Weight: 218 g (0.48 lb)
- MTBF: 1,403,659 hrs (Telcordia (Bellcore), GB)
- Compliance: RoHS, CRoHS, WEEE
- Package contents: 1 x DA-820-Ethernet Series expansion module, 1 x warranty card

FAQs

Q: Which computers is the DE-FX02-SFP-T compatible with?
A: It is an expansion module for Moxa DA-820 series x86 industrial computers and connects via the PCIe interface.

Q: Are SFP transceivers included?
A: No. The two SFP ports are supplied empty, so you need to purchase 100 Mbps SFP modules separately to suit your fibre type and distance.

Q: What is the difference between the DE-FX02-SFP-T and the DA-GX02-SFP-T?
A: Both are 2-port SFP fibre expansion modules for the DA-820 series. The DE-FX02-SFP-T runs at 100 Mbps, while the DA-GX02-SFP-T runs at 1000 Mbps.

Q: What operating temperature range does this module support?
A: The operating temperature range is -40 to 70°C (-40 to 158°F), making it suitable for harsh industrial environments.

Q: What is included in the box?
A: The package contains one DA-820-Ethernet Series expansion module and a warranty card.

Q: How many fibre ports does it add?
A: It adds two 100 Mbps SFP fibre ports to the host DA-820 series computer.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
