Description

The DA-PRP-HSR-I210 is a 2-port Gigabit LAN PRP/HSR expansion module for the Moxa DA-820C industrial computer. It adds two 10/100/1000BaseT(X) ports and two 100/1000BaseSFP ports in a combo design, supporting IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR) for zero-recovery-time network redundancy in mission-critical applications.

Built for demanding industrial environments, the module offers 1.5 kV built-in magnetic isolation and an operating temperature range of -25 to 55°C. It suits substation automation, power utility and other deployments where seamless failover and data integrity are essential, and extends the DA-820C with redundant networking without external hardware.

Features

- 2-port Giga LAN PRP/HSR module for the DA-820C
- IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR) compliant
- Dual Gigabit Ethernet combo port design for high-performance redundant network systems
- Zero-time recovery for high system availability and data integrity
- 1.5 kV built-in magnetic isolation for port protection
- Wide -25 to 55°C operating temperature range

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100/1000BaseT(X) PRP/HSR ports
- 2 x 100/1000BaseSFP PRP/HSR ports (combo design)
- IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR) compliant
- Magnetic isolation protection: 1.5 kV (built-in)
- Dimensions: 169.54 x 111.15 mm (6.68 x 4.38 in)
- Weight: 185 g (0.41 lb)
- Operating temperature: -25 to 55°C (-13 to 131°F)
- EMC: EN 55032/24
- EMI: CISPR 22, FCC Part 15B Class A
- Green product: RoHS, CRoHS, WEEE
- MTBF: 1,743,211 hrs (Telcordia SR332)

FAQs

Q: Which computer is the DA-PRP-HSR-I210 designed for?
A: It is an expansion module for the Moxa DA-820C industrial computer.

Q: Which redundancy protocols does it support?
A: It supports PRP (IEC 62439-3 Clause 4) and HSR (IEC 62439-3 Clause 5), providing zero recovery time on network failure.

Q: What ports does the module provide?
A: It provides two 10/100/1000BaseT(X) PRP/HSR ports and two 100/1000BaseSFP PRP/HSR ports in a combo design.

Q: What operating temperature range does it support?
A: The module operates from -25 to 55°C (-13 to 131°F).

Q: Does the module include built-in port protection?
A: Yes, it includes 1.5 kV built-in magnetic isolation protection.

Q: What environmental compliance does it meet?
A: It is RoHS, CRoHS and WEEE compliant, with EMC to EN 55032/24 and EMI to CISPR 22 and FCC Part 15B Class A.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
