• Moxa CP-114N-I-T 4-port serial card with black DB9 adapters and ribbon cable on green PCB
1 1

Moxa

Moxa CP-114N-I-T | 114N mPCIe Serial Card, 2.5 kV Isolated, 232/422/485, 4 x RS, CP

Moxa CP-114N-I-T | 114N mPCIe Serial Card, 2.5 kV Isolated, 232/422/485, 4 x RS, CP

CP-114N-I-T

Stock Status: Enquire

$0.00 AUD
$0.00 AUD
$0.00 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The CP-114N-I-T is a compact 4-port mini PCI Express serial card for embedded and industrial PCs that need reliable legacy serial connectivity in harsh environments. Each port is software-selectable for RS-232/422/485, supporting high-speed data over long runs with robust 2.5 kV isolation to protect edge devices and the host system. Engineered for extremes with a -40 to 85°C operating range and broad OS driver support, the CP-114N series streamlines integration in transportation, factory automation, and energy applications. Backed by Moxa’s industry-leading warranty and support. Visit iptrading.com.au to secure your order — enterprise-grade hardware with expert support.

Features

- Four flexible serial ports on a single mPCIe card for space-constrained systems
- Per-port RS-232/422/485 selection to match a wide range of industrial devices
- 2.5 kV isolation safeguards host PCs and field equipment
- Wide -40 to 85°C rating ensures reliable operation in harsh environments
- High-speed serial up to 921.6 kbps for demanding data capture and control
- Broad Windows and Linux driver support for fast integration

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Form factor: mini PCI Express (mPCIe)
- Ports: 4 x software-selectable RS-232/RS-422/RS-485
- Isolation: 2.5 kV per-port isolation
- Baud rate: up to 921.6 kbps
- Operating temperature: -40 to 85°C
- RS-485 modes: 2-wire and 4-wire with automatic data direction control
- Interface: host mPCIe (PCI Express Mini Card)
- Power: supplied by host mPCIe slot
- OS support: Windows and Linux drivers (kernel support varies by distro)

FAQs

Q: What systems can this card be installed into?
A: Any host with a mini PCI Express (mPCIe) slot, such as embedded/industrial PCs and compact edge computers that accept mPCIe expansion.

Q: Which serial standards are supported?
A: Each of the four ports can be configured as RS-232, RS-422, or RS-485. RS-485 supports both 2-wire and 4-wire modes with automatic data direction control.

Q: What is the isolation rating and why does it matter?
A: The card provides 2.5 kV isolation per port to protect the host and connected devices against ground loops and electrical transients commonly found in industrial environments.

Q: Is it suitable for wide-temperature deployments?
A: Yes. The CP-114N-I-T is rated for -40 to 85°C operation, making it suitable for outdoor cabinets, vehicles, and unconditioned plant floors.

Q: What operating systems are supported?
A: Windows and Linux are supported with vendor-provided drivers. Check Moxa’s driver matrix for specific OS and kernel versions.

Q: Can I purchase this in Australia from IP Trading?
A: Yes. IP Trading is an Australian supplier. Order directly at iptrading.com.au or contact the team for stock status, lead times, and integration advice.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
