Moxa BXP-C100-C1-8C-T | BXP-C100 Fanless Box PC, Celeron 6305E, 8GB, 10x Serial, 2x LAN

Authorised Moxa Partner

SKU:BXP-C100-C1-8C-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa BXP-C100-C1-8C-T is a fanless industrial box computer built on an Intel Celeron 6305E processor with 8 GB DDR4 memory. This variant provides 10 software-selectable RS-232/422/485 serial ports and 2 LAN ports, making it well suited to field and industrial applications that need to connect multiple serial devices to an x86 platform.

The BXP-C100 Series offers dual storage with CFast and SD slots, four digital inputs and four digital outputs, and VGA and HDMI video outputs. The -T model operates across a wide -30 to 60°C temperature range from a 12/24 VDC power input, and its compact wall-mountable chassis fits most field installations.

Features

- Fanless box-type design for reliable operation in field environments
- 11th Gen Intel Celeron processor for capable x86 industrial computing
- 10 software-selectable serial ports with 1.5 kV magnetic isolation protection
- Wide operating temperature range of -30 to 60°C
- Dual-storage design with CFast and SD slots
- Communication interfaces on front and rear for easy access and expansion
- Compact size to fit most field applications

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: Intel Celeron 6305E, dual core, 4M cache, 1.80 GHz
- RAM: 8 GB DDR4
- Storage slots: 1 x CFast, 1 x SD
- Serial ports: 10 x RS-232/422/485, software selectable, DB9 male
- Serial magnetic isolation protection: 1.5 kV built-in
- LAN ports: 2
- USB: 4 x USB 2.0, 2 x USB 3.0
- Digital I/O: 4 x DI, 4 x DO
- Video outputs: 1 x VGA, 1 x HDMI
- Power input: 12/24 VDC
- Operating temperature: -30 to 60°C
- Watchdog timer and RTC with lithium battery backup
- MTBF: 1,517,956 hrs (Telcordia)

FAQs

Q: How many serial ports does the BXP-C100-C1-8C-T have?
A: It provides 10 DB9 male serial ports, each software selectable between RS-232, RS-422 and RS-485, with built-in 1.5 kV magnetic isolation protection.

Q: Is the BXP-C100-C1-8C-T suitable for extreme temperatures?
A: Yes. As a -T model it operates from -30 to 60°C, and its fanless design suits harsh field and industrial environments.

Q: What storage options does it support?
A: It has one CFast slot and one SD slot, giving a dual-storage design for the operating system and data.

Q: What power input does it require?
A: It runs from a 12/24 VDC power input.

Q: Which video outputs are available?
A: It has one VGA output and one HDMI output.

Q: How does this model differ from other BXP-C100 Series variants?
A: This model uses an Intel Celeron 6305E processor with 8 GB DDR4 and offers 10 serial ports and 2 LAN ports. Other variants in the series offer different processor, memory and interface combinations.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
