Lenovo 4XB7A10247 | ThinkSystem S4510 240GB 2.5in Hot Swap SATA SSD

Name: Lenovo 4XB7A10247 | ThinkSystem S4510 240GB 2.5in Hot Swap SATA SSD
Brand: Lenovo
SKU: 4XB7A10247
Price: 325.11 AUD
Availability: InStock

Authorised Lenovo Partner

SKU:4XB7A10247

In stock:2

$325.11 inc. GST

$295.55 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ThinkSystem S4510 240GB 2.5-inch hot-swap SATA SSD is an enterprise solid state drive for ThinkSystem servers, built on Intel 64-layer 3D NAND TLC flash with a 6Gbps SATA interface. This 240GB, 2.5" SFF hot-swap model is optimised for read-intensive workloads such as server boot drives, web serving and light databases, delivering up to 560 MBps sequential read and 90,000 random read IOPS.

Endurance is rated at 2.1 DWPD, equal to 900 TB total bytes written, with an MTBF of 2,000,000 hours. Full end-to-end data path protection, enhanced power loss data protection and thermal throttling help protect data and extend drive life, while typical write power draw is as low as 2.4 W per drive.

Features

- Intel 64-layer 3D NAND TLC flash with a 6Gbps SATA interface
- Endurance of up to 2 DWPD for 5 years using Intel Standard Endurance Technology
- Typical write power consumption as low as 2.4 W per drive
- S.M.A.R.T. support
- Full end-to-end data path protection
- Thermal throttling to extend drive life
- Enhanced power loss data protection
- High reliability and enhanced ruggedness
- Tested through the Lenovo ServerProven program

Warranty

Lenovo offers a standard 1-year warranty across most product lines, including:
• PC Products: 1-year base warranty coverage for laptops, desktops, and other personal computing devices.
• Data Centre Products: 1-year base warranty for servers, storage, and networking hardware.
Warranty coverage includes repair or replacement for eligible defects in materials or workmanship under normal use conditions.
Extended Warranty Options:
IP Trading can offer extended warranty solutions tailored to your business needs. Please contact us for details on available Lenovo extended warranty packages.
https://support.lenovo.com/au/en/solutions/ht505088-product-warranty-and-other-agreements

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Capacity: 240 GB
- Form factor: 2.5-inch hot-swap tray (SFF)
- Interface: 6 Gbps SATA
- Flash: Intel 64-layer 3D NAND TLC
- Sequential read: 560 MBps (128 KB blocks)
- Sequential write: 280 MBps (128 KB blocks)
- Random read: 90,000 IOPS (4 KB blocks)
- Random write: 16,000 IOPS (4 KB blocks)
- Endurance: 2.1 DWPD, 900 TB total bytes written
- MTBF: 2,000,000 hours
- Data reliability: less than 1 in 10^17 bits read
- SED encryption: None
- Typical active write power: 2.4 W
- Feature code: B498

FAQs

Q: What form factor is the 4XB7A10247 SSD?
A: It is a 2.5-inch small form factor (SFF) hot-swap SATA SSD supplied for use in ThinkSystem server drive bays.

Q: What workloads is this drive suited to?
A: The ThinkSystem S4510 series is optimised for read-intensive workloads such as boot drives, web serving and light database use.

Q: What is the endurance rating of this SSD?
A: The 240GB model is rated at 2.1 drive writes per day, equal to 900 TB total bytes written.

Q: Does this drive support self-encrypting (SED) functionality?
A: No. This model has no SED encryption.

Q: What interface does it use?
A: It uses a 6 Gbps SATA interface, with sequential speeds of up to 560 MBps read and 280 MBps write.

Q: Is the drive hot-swappable?
A: Yes. It is supplied in a 2.5-inch hot-swap tray for ThinkSystem servers with hot-swap SATA drive bays.
