• Silver-colored metal juniper sfpp-10ge-er sfp+ transceiver with black connector housing and printed labeling for 10g single-mode use
1 1

Juniper

Juniper SFPP-10GE-ER | 10G SFP+ Transceiver, Single-Mode, 1550nm, 40km, LC

Juniper SFPP-10GE-ER | 10G SFP+ Transceiver, Single-Mode, 1550nm, 40km, LC

SFPP-10GE-ER

Stock Status: Enquire

$5,769.66 AUD
$5,769.66 AUD
$5,769.66 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The Juniper SFPP-10GE-ER is a 10GBASE-ER SFP+ transceiver engineered for extended-reach single-mode fibre deployments up to 40km. Operating at 1550nm with a duplex LC connector, it delivers 10 Gbps throughput over 9/125µm SMF — making it ideal for service provider edge router uplinks, backbone interconnects, provider aggregation, and mobile backhaul links. Multi-rate support across 1GE, 10GE, and STM-64 SONET/SDH transport gives network architects flexibility across mixed environments.

Built for seamless integration with Juniper MX, PTX, and ACX routing platforms, the SFPP-10GE-ER includes Digital Optical Monitoring (DOM) for real-time telemetry of transmit/receive power, laser bias, temperature, and supply voltage — all accessible via the Junos CLI. The module is RoHS compliant, CE marked, and Class 1 laser certified. Order now at iptrading.com.au — trusted by Australian IT professionals.

Features

- 10GBASE-ER extended reach — supports transmission up to 40km over single-mode fibre
- 1550nm DFB laser transmitter paired with PIN photodiode receiver for reliable long-haul performance
- Digital Optical Monitoring (DOM) — real-time visibility into Tx/Rx power, laser bias, temperature, and supply voltage
- Native Junos/EVO integration — fully recognised and manageable via 'show interfaces diagnostics optics' CLI command
- Multi-rate operation — compatible with 1GE, 10GE, and STM-64 SONET/SDH transport modes
- Compatible with Juniper MX, PTX, and ACX routing platforms
- RoHS compliant and CE marked for regulatory conformance
- Class 1 laser safety certified per IEC 60825-1 and FDA standards
- Suitable for service/edge router uplinks, provider aggregation, backbone links, and mobile backhaul

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: SFP+
- Data Rate: 10 Gbps (10GbE / 10GBASE-ER)
- Wavelength: 1550nm
- Fiber Type: Single-Mode Fiber (SMF), 9/125µm
- Maximum Reach: 40km
- Connector: Duplex LC
- Transmit Power: -1 dBm to +4 dBm
- Receiver Sensitivity: better than -16 dBm
- Receiver Overload: 0 dBm
- Link Budget: 15 dB
- Multi-rate Support: 1.25 to 11.32 Gbps (1GE, 10GE, STM-64 SONET/SDH)
- Digital Optical Monitoring (DOM): Yes
- MSA Compliance: SFF-8431 (electrical), SFF-8472 (DOM)
- Operating Temperature: 0°C to 70°C (commercial)
- Supply Voltage: +3.3V
- Certifications: RoHS, CE, Class 1 Laser (IEC 60825-1 / FDA)

FAQs

Q: What is the maximum transmission distance of the SFPP-10GE-ER?
A: The SFPP-10GE-ER supports a maximum reach of 40km over standard 9/125µm single-mode fibre (SMF) at 1550nm, making it suitable for long-haul service provider and enterprise backbone links.

Q: Which Juniper platforms are compatible with the SFPP-10GE-ER?
A: The SFPP-10GE-ER is designed for use on Juniper MX, PTX, and ACX routing platforms. It is fully integrated with Junos and Junos EVO operating systems for seamless recognition and telemetry.

Q: Does the SFPP-10GE-ER support Digital Optical Monitoring (DOM)?
A: Yes. The SFPP-10GE-ER supports DOM per SFF-8472 MSA, allowing real-time monitoring of transmit power, receive power, laser bias current, temperature, and supply voltage directly via the Junos CLI.

Q: What Ethernet standard does this transceiver conform to?
A: The SFPP-10GE-ER conforms to the 10GBASE-ER standard, operating at 10 Gbps over single-mode fibre. It also supports multi-rate operation at 1GE and STM-64 SONET/SDH for flexible deployment across mixed network environments.

Q: Can I purchase the Juniper SFPP-10GE-ER in Australia?
A: Yes. The SFPP-10GE-ER is available through iptrading.com.au, a trusted Australian B2B IT hardware reseller. IP Trading supplies Juniper optic modules to enterprise, government, and service provider customers across Australia.

Q: What type of fibre cable and connector does the SFPP-10GE-ER require?
A: The SFPP-10GE-ER requires 9/125µm single-mode fibre (SMF) with a duplex LC connector. Ensure your patch cable and fibre infrastructure are rated for SMF to achieve the full 40km reach specification.
