Juniper MIC-3D-4XGE-XFP | MX Series MIC 4-Port 10GbE Router Module, XFP, Optics Sold Separately

Juniper MIC-3D-4XGE-XFP | MX Series MIC 4-Port 10GbE Router Module, XFP, Optics Sold Separately

MIC-3D-4XGE-XFP

Stock Status: Enquire

$0.00 AUD
$0.00 AUD
$0.00 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The MIC-3D-4XGE-XFP is a 4-port 10 Gigabit Ethernet Modular Interface Card (MIC) designed for Juniper MX Series routers, delivering high-throughput 10GbE connectivity via XFP optics. Purpose-built for service provider and enterprise core networks, it slots into MPC2 and MPC3E-class line cards across the MX240, MX480, MX960, MX2010, and MX2020 platforms, enabling scalable, modular router architecture without chassis replacement. XFP optics are sold separately, giving network engineers flexibility to choose the appropriate reach and media type for their deployment.

Managed through Juniper Junos OS, the MIC-3D-4XGE-XFP supports advanced protocols including IPv6, MPLS, BGP, and OSPFv2/OSPFv3, making it well suited for carrier-grade routing environments and high-density data centre interconnects. Its hot-swappable design minimises maintenance windows by allowing installation and replacement without disrupting live network operations. Order today at iptrading.com.au — your local source for enterprise-grade networking solutions.

Features

- 4 x 10GbE XFP interfaces for high-throughput core and edge routing connectivity
- Hot-swappable design enables installation and replacement without network downtime
- Modular architecture slots into MPC2/MPC3E-class line cards for scalable MX Series deployments
- Managed via Juniper Junos OS for consistent configuration, monitoring, and troubleshooting
- Supports IPv6, MPLS, BGP, OSPFv2, and OSPFv3 for carrier-grade routing environments
- Flexible XFP transceiver support allows choice of reach and media type to suit deployment needs
- Not compatible with MPC1 — exclusively supported on MPC2 and MPC3E-class cards

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x 10GbE XFP ports
- Port speed: 10 Gbps per port
- Transceiver type: XFP (optics sold separately)
- Form factor: MIC (Modular Interface Card)
- Supported line cards: MX-MPC2, MPC2E-3D-NG, MPC2E-3D-NG-Q, MPC3E-3D-NG, MPC3E-3D-NG-Q
- Compatible platforms: MX240, MX480, MX960, MX2010, MX2020
- Ethernet LAN data rates: 10/100/1000/10000 Mbit/s
- Operating system: Juniper Junos OS

FAQs

Q: Which Juniper MX Series platforms support the MIC-3D-4XGE-XFP?
A: The MIC-3D-4XGE-XFP is compatible with the MX240, MX480, MX960, MX2010, and MX2020 platforms when installed into supported MPC2 or MPC3E-class line cards, including MX-MPC2, MPC2E-3D-NG, MPC2E-3D-NG-Q, MPC3E-3D-NG, and MPC3E-3D-NG-Q.

Q: Does the MIC-3D-4XGE-XFP include XFP optics?
A: No, XFP optics are sold separately. This gives you the flexibility to select the appropriate transceiver for your distance and media requirements — whether short-range multimode or long-reach single-mode fibre.

Q: Is the MIC-3D-4XGE-XFP compatible with MPC1 line cards?
A: No, the MIC-3D-4XGE-XFP is not supported on MPC1. It is exclusively compatible with MPC2 and MPC3E-class line cards. Always verify your chassis and MPC version before ordering.

Q: Can this MIC be replaced without taking the router offline?
A: Yes, the MIC-3D-4XGE-XFP features a hot-swappable design, allowing technicians to install or replace the card without disrupting live router operations, minimising maintenance windows in production environments.

Q: What routing protocols does this MIC support?
A: When installed in a compatible MX Series router running Junos OS, the MIC-3D-4XGE-XFP supports a full suite of enterprise and carrier-grade protocols including IPv6, MPLS, BGP, OSPFv2, and OSPFv3.

Q: Can I purchase the MIC-3D-4XGE-XFP in Australia through IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian B2B IT hardware reseller with stock of Juniper MX Series modules including the MIC-3D-4XGE-XFP. Contact our team for pricing, lead times, and compatibility advice tailored to your network environment.
