Juniper ACX7100-32C-LDC-AO | ACX7100-32C Cloud Metro Router, 32x 100G QSFP28, 4x 400G, DC, AFO

Authorised Juniper Partner

SKU:ACX7100-32C-LDC-AO

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Juniper ACX7100-32C-LDC-AO is a 1U fixed cloud metro router with 4.8 Tbps forwarding capacity, built for dense 100GbE fan-out with 400GbE uplinks. This variant is DC powered with front-to-back airflow (AFO) and ships with the limited-feature (LDC) software licence, making it suited to telco and data centre racks that run on -48 to -60 VDC.

The ACX7100-32C provides 32 x 100GbE QSFP28 ports (also supporting 40GbE QSFP+) and 4 x 400GbE QSFP56-DD multi-rate ports, running Junos OS Evolved. It is designed for the IP service fabric in cloud metro, aggregation and edge deployments, with a thermal design that supports high-power ZR/ZR+ coherent transceivers on all supporting ports.

Features

- Runs Junos OS Evolved
- Thermal design supports high-power ZR/ZR+ coherent transceivers on all supporting ports
- Hot-swappable, field-replaceable fans and power supplies
- MACsec support on all ports
- PTP grandmaster clock support (1GbE via QSA adaptor on port 31)
- Designed for the IP service fabric in cloud metro, aggregation and edge deployments

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 32 x 100GbE QSFP28 ports (also supports 40GbE QSFP+)
- 4 x 400GbE QSFP56-DD ports (multi-rate)
- 4.8 Tbps ASIC throughput
- 1U fixed chassis, 44.09 x 4.45 x 59.49 cm (17.36 x 1.75 x 23.42 in)
- Weight approx. 12.7 kg (28.0 lb) fully configured
- Dual redundant DC power supplies, -48 to -60 VDC rated (1600 W, dual feeds)
- Typical power consumption 570 W, maximum 960 W (without optics)
- 6 fan modules (5+1 redundancy), front-to-back airflow (AFO)
- 2.9 GHz six-core Intel CPU, 64 GB DRAM, 200 GB (2 x 100 GB) internal storage
- Maximum port capacity: 4 x 400GbE, 48 x 100GbE (with breakout), 96 x 50GbE, 80 x 25GbE/10GbE

FAQs

Q: What power input does the ACX7100-32C-LDC-AO use?
A: This variant uses dual redundant DC power supplies rated for -48 to -60 VDC (1600 W, dual feeds). It is not an AC-powered model.

Q: What does AFO mean in this part number?
A: AFO denotes front-to-back airflow. The six fan modules (5+1 redundancy) draw air through the front of the chassis and exhaust it at the rear.

Q: What does the LDC licence level mean?
A: LDC indicates the limited-feature software licence included with this SKU. It runs Junos OS Evolved, with the licence tier determining the available feature set.

Q: What port speeds does the ACX7100-32C support?
A: It provides 32 x 100GbE QSFP28 ports (which also support 40GbE QSFP+) and 4 x 400GbE QSFP56-DD multi-rate ports. With breakout, it can reach up to 48 x 100GbE, 96 x 50GbE or 80 x 25GbE/10GbE.

Q: Can it run coherent ZR/ZR+ optics?
A: Yes. The thermal design supports high-power ZR/ZR+ coherent transceivers on all supporting ports.

Q: Are the fans and power supplies replaceable in the field?
A: Yes. The fans and power supplies are hot-swappable and field-replaceable, so they can be changed without taking the router offline.
