HPE S1H41A | MSA 2070 16Gb Fibre Channel LFF Storage Array, 2U, 12-Bay

Authorised HPE Partner

SKU:S1H41A

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The HPE MSA 2070 16Gb Fibre Channel LFF storage array is an entry-level shared SAN storage system in a 2U rack-mount chassis with 12 x 3.5" large form factor drive bays. It ships with two 16Gb Fibre Channel 4-port controllers and two redundant 580W power supplies, making it suited to SMB and enterprise workloads that need simple, fast and affordable block storage.

Part of the HPE MSA Gen7 family, it supports SAS-3 HDD and SSD media, automated real-time data tiering in hybrid configurations, and MSA-DP+ advanced RAID for faster rebuilds. Capacity scales with up to 9 additional MSA 2U LFF or SFF drive enclosures, reaching up to 6.78 PB. Setup and day-to-day management are handled through the graphical MSA Storage Management Utility, with the cloud-based MSA Health Check included.

Features

- Up to 2x more random IOPS and 30% more sequential bandwidth than MSA Gen6
- Simple setup via the graphical MSA Storage Management Utility with guided workflows
- Hot-swap controllers, drives and power supplies for minimal downtime
- Online controller and media firmware updates
- Automated real-time data tiering across SSD and HDD in hybrid configurations
- MSA-DP+ advanced RAID distributes spare capacity across all drives, with rebuilds up to 25x faster than traditional RAID
- Scales beyond 7 PB per array with expansion enclosures
- Cloud-based MSA Health Check at no additional charge
- Certified for use with HPE Morpheus VM Essentials Software

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 2U rack-mount, large form factor (LFF) array
- 12 x 3.5" LFF drive bays (SAS-3, HDD and/or SSD)
- 2 x 16Gb Fibre Channel 4-port controllers
- 2 x 580W redundant power supplies
- Up to 6.78 PB with maximum capacity expansion
- Expandable with up to 9 additional MSA 2U LFF 12-drive and/or SFF 24-drive enclosures
- RAID technology: HPE MSA-DP+
- Management: MSA Storage Management Utility (SMU), HPE MSA Health Check
- Compatible operating systems: Windows Server, VMware vSphere, Red Hat Linux, SUSE SLES

FAQs

Q: What host connectivity does the HPE S1H41A support?
A: It includes two 16Gb Fibre Channel controllers, each with 4 ports, for connection to a Fibre Channel SAN.

Q: What drives does the MSA 2070 LFF array take?
A: It has 12 x 3.5" large form factor bays for SAS-3 HDD and/or SSD media.

Q: How can I expand capacity?
A: The base array can be expanded with up to 9 additional MSA 2U LFF 12-drive and/or SFF 24-drive enclosures, for up to 6.78 PB at maximum expansion.

Q: Which operating systems are supported?
A: Windows Server, VMware vSphere, Red Hat Linux and SUSE SLES are listed as compatible.

Q: Does it have redundant power and controllers?
A: Yes. It ships with two redundant 580W power supplies and two controllers, and controllers, drives and power supplies are hot-swappable.

Q: How is the array managed?
A: Through the graphical MSA Storage Management Utility (SMU) with guided workflows, plus the cloud-based MSA Health Check.
