HPE P80429-B21 | ProLiant DL580 Gen12 Drive Cage Kit, 8SFF, x1 U.3 Tri-Mode

Name: HPE P80429-B21 | ProLiant DL580 Gen12 Drive Cage Kit, 8SFF, x1 U.3 Tri-Mode
Brand: HPE
SKU: P80429-B21
Price: 919.95 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:P80429-B21

Stock Status: Enquire

$919.95 inc. GST

$836.32 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

This 8SFF x1 U.3 Tri-Mode drive cage kit is a front drive cage option for the HPE ProLiant Compute DL580 Gen12 4U rack server. It holds eight small-form-factor drives and connects through a Tri-Mode (x1) storage controller, supporting NVMe, SAS and SATA drives in the same cage.

The kit is designed to be combined with additional cages in x1 Tri-Mode layouts, helping you scale front drive capacity as storage needs grow. It works with PCIe-slot or OCP-slot Tri-Mode controllers, including the MR416i-p, MR216i-p and MR408i-p, as well as the -o variants. A matching controller and cable kit are required to complete the installation.

Features

- Eight SFF front drive bays in a single cage for the DL580 Gen12
- U.3 Tri-Mode support for NVMe, SAS and SATA drives
- The DL580 Gen12 chassis supports up to four 8SFF or 8EDSFF front drive cages, and up to 32 mixed EDSFF or SFF drives
- Can be combined with additional cages (16SFF, 24SFF, 32SFF) in x1 Tri-Mode layouts
- Works with PCIe-slot or OCP-slot Tri-Mode controllers
- Cable kits are configured automatically based on the drive cage and riser selections

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P80429-B21
- Compatible server: HPE ProLiant Compute DL580 Gen12 (4U rack)
- Drive bays: 8SFF
- Drive interface: U.3 Tri-Mode (NVMe/SAS/SATA), x1
- Protocol / controller type: PCIe Tri-Mode (TM) or OROC Tri-Mode (TM)
- Supported PCIe controllers: MR416i-p, MR216i-p, MR408i-p
- Supported OCP (OROC) controllers: MR416i-o, MR216i-o, MR408i-o
- Controller quantity (8SFF x1): 1
- Cable kit (PCIe controller): P80387-B21, uses PCIe slot 7
- Cable kit (OCP controller): P80391-B21, uses OCP slot B
- Drive box position: Box 3 (first cage in a 2P/4P configuration)

FAQs

Q: Which server is this drive cage kit for?
A: It is for the HPE ProLiant Compute DL580 Gen12 4U rack server.

Q: What drive types does it support?
A: It supports U.3 Tri-Mode drives, meaning NVMe, SAS and SATA, across eight SFF bays at x1 per drive.

Q: Do I need a separate controller?
A: Yes. It requires a Tri-Mode controller: MR416i-p, MR216i-p or MR408i-p in a PCIe slot, or the MR416i-o, MR216i-o or MR408i-o OCP variants.

Q: Which cable kit does it need?
A: A PCIe controller uses cable kit P80387-B21 in PCIe slot 7, while an OCP controller uses cable kit P80391-B21 in OCP slot B.

Q: Can I add more drive cages alongside this one?
A: Yes. The DL580 Gen12 chassis supports up to four 8SFF or 8EDSFF front cages, and this cage can be combined with 16SFF, 24SFF and 32SFF x1 Tri-Mode layouts.

Q: Where does this cage sit in a multi-processor configuration?
A: It occupies drive Box 3, as the first cage in a 2P or 4P configuration.
