HPE

HPE P78279-B21 | NS204i-u v2 480GB NVMe Hot-Plug Boot Device, DL365/DL385 Gen11/12

HPE P78279-B21 | NS204i-u v2 480GB NVMe Hot-Plug Boot Device, DL365/DL385 Gen11/12

P78279-B21

Stock Status: Enquire

$3,950.60 AUD
$3,950.60 AUD
$3,950.60 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The HPE NS204i-u v2 Boot Optimized Storage Device delivers a dedicated NVMe OS boot solution for HPE DL365, DL385 Gen11, and Gen12 platforms — without consuming a PCIe slot or drive bay. Featuring two preconfigured 480GB M.2 NVMe SSDs in hardware RAID 1, it auto-mirrors the operating system at plug-in with zero GUI configuration required, delivering up to 4x faster read performance than legacy SATA boot solutions. Hot-plug installation, native NVMe driver compatibility with Windows, Linux, and VMware, and integrated power loss protection make this the enterprise-grade choice for segregating OS from data storage in virtualised server environments.

Designed exclusively for HPE Compute Mainstream platforms, the NS204i-u v2 requires no cables or backplanes, presents as a single directly connected NVMe volume, and meets VMware and Microsoft Storage Spaces Direct certification requirements. All existing drive bays remain available for data storage, maximising usable server capacity. Order direct from iptrading.com.au — Australian-owned and operated since 2001.

Features

- Hot-plug universal installation — dedicated slot, no PCIe slot or drive bay consumed
- No cables or backplanes required for installation
- Auto-creates RAID 1 volume at plug-in — zero GUI or user configuration needed
- Presents as a single directly connected NVMe drive to OS and management interface
- Native NVMe driver support for Windows, Linux, and VMware — no third-party drivers needed
- Up to 4x faster read performance versus legacy SATA boot solutions
- HPE enterprise-class M.2 NVMe SSDs with power loss protection and error correction
- Segregates OS storage from data storage plane — ideal for virtualised environments
- All server drive bays remain free for data storage
- Meets VMware and Microsoft Storage Spaces Direct certification requirements
- Compatible with HPE DL365 Gen11, DL385 Gen11, and DL385 Gen12 platforms

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Capacity: 2 x 480GB M.2 2280 NVMe SSDs (960GB total installed)
- Usable capacity: 480GB (RAID 1 mirrored)
- RAID: Preconfigured hardware RAID 1 (auto-configured, no setup required)
- Interface: PCIe Gen3
- Form factor: Dedicated hot-plug slot (no PCIe slot consumed)
- Maximum drives supported: 2 (included in kit)
- Compatible platforms: HPE DL365 Gen11, DL385 Gen11, DL385 Gen12
- OS support: Windows, Linux, VMware (native NVMe drivers)
- Dimensions: 8.75 x 9.94 x 2.56 in
- Weight: 0.421 lb
- Compliance: RoHS, ErP Lot 9
- Warranty: 3-year (3/0/0, subject to maximum usage limitations)

FAQs

Q: Which HPE servers is the NS204i-u v2 compatible with?
A: The HPE NS204i-u v2 (P78279-B21) is compatible with HPE ProLiant DL365 Gen11, DL385 Gen11, and DL385 Gen12 platforms. It is not compatible with older generations or other ProLiant models outside this family.

Q: Does the NS204i-u v2 require a dedicated PCIe slot?
A: No. The NS204i-u v2 installs into a dedicated boot device slot and does not consume any PCIe slot. It also requires no cables or backplanes, leaving all drive bays fully available for data storage.

Q: Does the RAID 1 mirror need to be configured manually?
A: No. The NS204i-u v2 auto-creates a RAID 1 volume upon installation with no GUI, software, or user configuration required. It presents as a single directly connected NVMe drive to the management interface and OS.

Q: Is this device compatible with VMware and Microsoft Storage Spaces Direct?
A: Yes. The NS204i-u v2 meets VMware certification requirements and Microsoft Storage Spaces Direct certification, making it suitable for hypervisor deployments and software-defined storage environments.

Q: How does the NS204i-u v2 compare to legacy SATA boot solutions?
A: The NS204i-u v2 delivers up to 4x faster read performance compared to legacy SATA-based boot devices, thanks to its NVMe M.2 SSDs with PCIe Gen3 interface and enterprise-class error correction with power loss protection.

Q: Can I purchase the HPE NS204i-u v2 in Australia from IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian-owned and operated IT hardware reseller, trading since 2001. The P78279-B21 can be ordered directly through the site with local support and procurement assistance.
