HPE P75085-B21 | ProLiant DL320 Gen12 8SFF x4 NVMe U.3 Storage Backplane Kit

HPE P75085-B21 | ProLiant DL320 Gen12 8SFF x4 NVMe U.3 Storage Backplane Kit

P75085-B21

Stock Status: Enquire

$218.84 AUD
$218.84 AUD
$218.84 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The HPE ProLiant DL320 Gen12 Storage Backplane Kit delivers 8 Small Form Factor (2.5") drive bays with x4 NVMe U.3 connectivity, purpose-built for the DL320 Gen12 1U server platform. Engineered for high-performance NVMe direct-attach storage deployments, this kit supports hot-plug drive replacement to minimise downtime and enables maximum per-bay throughput via PCIe x4 lanes per port — making it an ideal upgrade for data-intensive workloads in space-constrained environments.

The backplane integrates seamlessly with the DL320 Gen12 chassis, aligning with HPE Gen12 mechanical, electrical, and airflow standards. SATA SFF drives are also supported when paired with a compatible storage controller, offering configuration flexibility. Available as a Configure-to-Order (CTO) option, this kit is suited for enterprises looking to maximise storage density in a 1U footprint. Upgrade your network with gear from iptrading.com.au — Australia's IT hardware specialists.

Features

- Enables high-density NVMe U.3 storage within the DL320 Gen12 1U chassis
- x4 PCIe lanes per drive bay for maximum per-port NVMe throughput
- Hot-plug drive support across all 8 SFF bays minimises planned maintenance windows
- Seamless mechanical and electrical integration with HPE ProLiant Gen12 platform
- NVMe Direct Attach mode supported when sufficient PCIe lanes are available
- SATA SFF drive compatibility available with an appropriate HPE storage controller
- Optimised for HPE Gen12 airflow and cable routing standards
- Configure-to-Order (CTO) option for flexible SFF server build specifications

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Drive Bays: 8 x SFF (2.5") Hot-Plug
- Backplane Interface: x4 NVMe U.3 per port
- Compatible Server: HPE ProLiant Compute DL320 Gen12
- Form Factor: 1U chassis integration
- Drive Support: NVMe U.3 (direct attach); SATA SFF with compatible controller
- Hot-Plug: Yes
- NVMe Mode: Direct Attach (PCIe lane availability required)
- Part Number: P75085-B21

FAQs

Q: Which server is this backplane kit compatible with?
A: The P75085-B21 is designed exclusively for the HPE ProLiant Compute DL320 Gen12 server. It is not compatible with earlier Gen10/Gen11 platforms or other ProLiant models.

Q: Does this backplane support hot-plug drive replacement?
A: Yes. All 8 SFF bays support hot-plug functionality, allowing drives to be replaced without powering down the server — minimising operational downtime in production environments.

Q: Can I use SATA drives with this backplane?
A: Yes, SATA SFF drives are supported when used with a compatible HPE storage controller. NVMe U.3 direct-attach operation requires available PCIe lanes from the host system.

Q: What does x4 NVMe U.3 mean and why does it matter?
A: x4 NVMe U.3 means each drive bay connects via four PCIe lanes using the U.3 multi-protocol interface, delivering full NVMe bandwidth per bay. This results in significantly higher throughput and lower latency compared to SATA or SAS backplanes, ideal for demanding storage workloads.

Q: Is this available as a configure-to-order (CTO) option?
A: Yes, the P75085-B21 is offered as a CTO backplane option for SFF DL320 Gen12 server configurations, allowing it to be specified at time of order through HPE or authorised resellers like IP Trading.

Q: Can I purchase this backplane kit in Australia through IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian B2B IT hardware specialist and can supply the HPE P75085-B21 backplane kit. Contact the team for pricing, availability, and compatibility advice tailored to your DL320 Gen12 deployment.
