HPE P75084-B21 | ProLiant DL3xx Gen12 1U 8SFF Tri-Mode U.3 L-Shaped Backplane Kit

HPE P75084-B21 | ProLiant DL3xx Gen12 1U 8SFF Tri-Mode U.3 L-Shaped Backplane Kit

P75084-B21

Stock Status: Enquire

$0.00 AUD
$0.00 AUD
$0.00 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

Purpose-built for HPE ProLiant DL3xx Gen12 1U servers, this L-shaped backplane enables up to eight 2.5" bays with Tri-Mode U.3 connectivity for NVMe, SAS, or SATA drives.. It delivers flexible storage configuration, consistent signal integrity, and clean cable routing in dense 1U chassis. Designed for reliability and serviceability, it supports hot-plug operation when paired with supported HPE controllers and chassis.. Covered by HPE limited warranty—check HPE documentation for details.. iptrading.com.au — your local source for enterprise-grade networking solutions.

Features

- Tri-Mode flexibility: use NVMe, SAS, or SATA drives on one backplane
- Dense 1U storage: enables up to eight SFF bays in compact servers
- Optimised layout: L-shaped design improves airflow and cable management
- Serviceability: hot-plug ready with supported controllers and chassis
- Enterprise-grade: HPE qualified for reliability and interoperability
- Future-ready: U.3 interface supports next-gen NVMe performance

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 1U L-shaped backplane for front 8 x SFF (2.5") bays
- Interface standard: U.3 Tri-Mode supporting NVMe, SAS, and SATA drives
- Drive capacity: up to 8 SFF drives
- Server compatibility: HPE ProLiant DL3xx Gen12 1U servers (select models)
- Hot-plug support: yes, when used with supported controllers and chassis
- Controller requirement: HPE Tri-Mode (NVMe/SAS/SATA) HBA/RAID controller required
- Drive connector: U.3 (SFF-8639) interfaces on the backplane
- Kit contents: L-shaped backplane assembly; mounting hardware

FAQs

Q: What does Tri-Mode U.3 mean on this backplane?
A: Tri-Mode U.3 allows the same backplane to support NVMe, SAS, and SATA 2.5" drives, providing maximum flexibility for performance and capacity mixes.

Q: Which servers is this backplane compatible with?
A: It is designed for select HPE ProLiant DL3xx Gen12 1U servers with 8 SFF front-bay configurations (e.g., DL360 Gen12 variants). Always check your server’s QuickSpecs for exact support.

Q: Can I mix NVMe and SAS/SATA drives on the same backplane?
A: Yes, the backplane supports mixed media; actual mixing and bay mapping depend on the Tri-Mode controller and cabling configuration used.

Q: Do I need a specific controller to use NVMe on this backplane?
A: Yes. An HPE Tri-Mode (NVMe/SAS/SATA) HBA or Smart Array controller is required to enable NVMe and multi-protocol support.

Q: Is hot-plug supported for drives connected to this backplane?
A: Hot-plug is supported when used with compatible HPE ProLiant chassis and supported Tri-Mode controllers with the correct firmware.

Q: Can I purchase this HPE kit from IP Trading in Australia?
A: Yes. IP Trading is an Australian supplier and can provide genuine HPE options with local support and tax invoice.
