HPE P72596-B21 | ProLiant DL360 Gen12 Front Primary OCP NIC Enablement Kit, Box 3 Bay 3

Name: HPE P72596-B21 | ProLiant DL360 Gen12 Front Primary OCP NIC Enablement Kit, Box 3 Bay 3
Brand: HPE
SKU: P72596-B21
Price: 1302.23 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:P72596-B21

Stock Status: Enquire

$1,302.23 inc. GST

$1,183.85 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The HPE ProLiant DL360 Gen12 Front Primary OCP NIC Enablement Kit adds a front-panel OCP NIC 3.0 slot to the 10 SFF / 20 E3.S hybrid server, positioned at Box 3, Bay 3. It carries the NIC signal from the rear OCP slot to the front of the chassis, giving easier access to network ports and better cooling for the installed adapter.

This is the Front Primary kit, and the Bay 3 slot is the only front position that provides Shared NIC (NC-SI) and Wake-on-LAN support. The kit includes a 4 E3.S drive cage, PHY board, primary front OCP NIC cable and OCP NIC interposer. It can be paired with the Front Secondary kit (P72597-B21, Box 3 Bay 1) for a dual-slot front OCP deployment.

Features

- Moves OCP NIC ports to the front panel for more convenient access
- Improved cooling for the installed NIC, with front placement of a high-cooling-level OCP NIC reducing downstream heat and allowing 30C system inlet temperature
- Single-slot front OCP deployment, or dual-slot when paired with P72597-B21
- Only the Bay 3 slot offers the Shared NIC (NC-SI) iLO connection
- PHY board links the front OCP NIC to the OCP interposer for iLO shared network

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P72596-B21
- Compatible server: HPE ProLiant Compute DL360 Gen12 (10 SFF / 20 E3.S, 10SFF/20EDSFF Hybrid CTO)
- Installation location: Box 3, Bay 3 OCP slot
- Front OCP slot interface: PCIe 5.0 x16
- Shared NIC (NC-SI): supported on Box 3 / Bay 3
- Wake-on-LAN: supported
- Kit contents: 4 E3.S drive cage, front OCP NIC cable bracket, E3.S drive filler, PHY board, primary front OCP NIC cable, OCP NIC interposer
- Interposer installs in rear Slot 14 OCP A PCIe 5.0 x16
- Supports up to 4 E3.S drives or up to 2 front OCP NICs in the drive cage
- Bezel kit cannot be selected together with this kit

FAQs

Q: Which servers is the P72596-B21 kit compatible with?
A: It is designed for the HPE ProLiant Compute DL360 Gen12 10 SFF / 20 E3.S (10SFF/20EDSFF Hybrid CTO) server only.

Q: What is the difference between P72596-B21 and P72597-B21?
A: P72596-B21 is the Front Primary kit for Box 3, Bay 3 and supports Shared NIC (NC-SI) and Wake-on-LAN. P72597-B21 is the Front Secondary kit for Box 3, Bay 1 and requires the primary kit to be installed.

Q: Does this kit include the OCP NIC adapter itself?
A: No. It is an enablement kit containing the drive cage, PHY board, front OCP NIC cable and OCP NIC interposer. The OCP NIC 3.0 adapter is selected separately.

Q: Does it support Shared NIC and Wake-on-LAN?
A: Yes. The Bay 3 slot enabled by this kit provides Shared NIC (NC-SI) for iLO and Wake-on-LAN. Only the Front Primary OCP Bay 3 slot provides Shared NIC.

Q: Can it be ordered with the server bezel kit?
A: No. The bezel kit cannot be selected together with this front OCP enablement kit.

Q: What PCIe interface does the front OCP slot use?
A: The front OCP slot operates as PCIe 5.0 x16, with the interposer installed in the rear Slot 14 OCP A PCIe 5.0 x16 position.
