Fortinet FVE-200F8 | FortiVoice 200F8 IP PBX, 8x FXO, 200 Endpoints

Fortinet FVE-200F8 | FortiVoice 200F8 IP PBX, 8x FXO, 200 Endpoints

Authorised Fortinet Partner

FVE-200F8

Stock Status: Enquire

$9,089.49 inc. GST
$8,263.17 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiVoice 200F8 is a 1U rack-mount IP PBX phone system built for small to mid-sized businesses that need to blend traditional analogue lines with VoIP. It provides 8 FXO ports, two Gigabit RJ45 network ports, 250 GB of onboard storage, support for up to 200 endpoints and 24 VoIP trunks, and handles up to 45 concurrent calls.

All core calling features are included without additional licences or cards, covering auto attendants, ring groups, call queues, call barge and call recording. Optional Call Center and Hotel licences extend the platform for specialised environments, and local survivable configuration keeps branch sites connected during outages when paired with a FortiVoice Gateway.

Features

- All core calling features included, with no additional licences or cards required
- Auto attendants, auto-provisioning, line and extension appearance, ring groups, call queue, call barge and call recording
- Local survivable configuration with a FortiVoice Gateway for continuity during outages
- Centralised management with call reports, real-time monitoring and a user web portal
- High availability (HA), NAS support, 802.1Q VLAN, SNMP, SRTP and voice QoS
- Optional Call Center and Hotel/property management licensing
- Mobile soft client support

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 2 x 10/100/1000 RJ45 network ports
- 8 x FXO ports
- 0 x FXS analogue extension ports
- 0 x PRI (T1/E1) ports
- 250 GB internal storage, no RAID
- Up to 200 endpoints (extensions)
- 24 VoIP trunks
- 45 concurrent calls
- 20 auto attendants
- 10 conference bridges, 8 attendees per bridge
- Up to 20 call centre agents
- Audio codecs: G.711 u-law/A-law, G.729a, G.722, Opus
- Video codecs: H.263, H.264
- 1U rack mount, single power supply
- Dimensions: 44 x 432 x 270 mm
- Weight: 4.54 kg

FAQs

Q: How many extensions and trunks does the FortiVoice 200F8 support?
A: It supports up to 200 endpoints (extensions) and 24 VoIP trunks, with up to 45 concurrent calls.

Q: Can I connect analogue phone lines to the FVE-200F8?
A: Yes. It has 8 FXO ports for traditional telephone lines. It does not include FXS ports or PRI (T1/E1) interfaces.

Q: Does the FVE-200F8 support call centre or hotel deployments?
A: Yes. Call Center and Hotel licences are supported as optional add-ons, with up to 20 call centre agents.

Q: What happens to phone service if the main site goes offline?
A: Local survivable configuration is supported when used with a FortiVoice Gateway, so branch sites can keep making and receiving calls during outages.

Q: What network connectivity does it provide?
A: It has two 10/100/1000 RJ45 ports and supports 802.1Q VLAN tagging, SRTP for encrypted media and voice QoS.

Q: What form factor is the FortiVoice 200F8?
A: It is a 1U rack-mount appliance measuring 44 x 432 x 270 mm with a single power supply and 250 GB of internal storage.
