Fortinet FG-7040E-PS-AC | 1500W AC Hot-Swap Power Supply Module

Fortinet FG-7040E-PS-AC | 1500W AC Hot-Swap Power Supply Module

Authorised Fortinet Partner

FG-7040E-PS-AC

Stock Status: Enquire

$3,978.99 inc. GST
$3,617.26 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FG-7040E-PS-AC is a 1500W AC hot-swappable power supply module for FortiGate chassis-based firewalls. It accepts 100-240 VAC input at 50-60 Hz and provides redundant power for the FortiGate 7040E, which runs three modules in a 2+1 redundant configuration with an optional fourth unit.

This module is also listed as compatible with the FortiGate 7030E, 6300F/6301F, 6500F/6501F, 3500F/3501F, 3700F/3701F, 3900E, 3960E and 3980E platforms. It is not compatible with the FortiGate 7060E. The power cord (SP-FGPCORC15-XX) is not included and must be ordered separately.

Features

- Hot-swappable redundant power for FortiGate 7000E chassis
- Supports 2+1 redundancy, with an optional fourth PSU in the 7040E
- Wide 100-240 VAC input range for global power environments

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1500W AC power supply unit
- Input: 100-240 VAC, 50-60 Hz
- Hot-swappable module
- 2+1 redundant configuration in the FortiGate 7040E (three PSUs, optional fourth)
- Compatible with FG-7030E, FG-7040E, FG-6300F/6301F, FG-6500F/6501F, FG-3500F/3501F, FG-3700F/3701F, FG-3900E, FG-3960E, FG-3980E
- Not compatible with FG-7060E
- Power cord SP-FGPCORC15-XX not included

FAQs

Q: Which FortiGate chassis use the FG-7040E-PS-AC?
A: It is used in the FortiGate 7040E, and is also listed as compatible with the FG-7030E, FG-6300F/6301F, FG-6500F/6501F, FG-3500F/3501F, FG-3700F/3701F, FG-3900E, FG-3960E and FG-3980E.

Q: Is this power supply compatible with the FortiGate 7060E?
A: No. The FG-7040E-PS-AC is not compatible with the FG-7060E.

Q: Is a power cord included with the module?
A: No. The SP-FGPCORC15-XX power cord is not included and must be ordered separately.

Q: Can the power supply be replaced while the firewall is running?
A: Yes. The module is hot-swappable, so it can be replaced without taking the chassis offline when redundancy is in place.

Q: How many power supplies does the FortiGate 7040E use?
A: The FortiGate 7040E runs three PSUs in a 2+1 redundant configuration, with an optional fourth unit.

Q: What AC input does this module accept?
A: It accepts 100-240 VAC at 50-60 Hz and delivers 1500W.
