• White Fortinet FortiGate 21C FEX-200F firewall with 5x GbE ports and LEDs
1 1

Fortinet

Fortinet FEX-200F | FortiExtender 200F LAN Extender, 5x GbE RJ45 WAN/LAN

Fortinet FEX-200F | FortiExtender 200F LAN Extender, 5x GbE RJ45 WAN/LAN

Authorised Fortinet Partner

FEX-200F

In stock:9

$437.89 inc. GST
$398.08 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiExtender 200F is an Ethernet-only LAN extender that extends the FortiGate LAN interface over a secured Layer 2 tunnel, delivering Layer 2 to Layer 7 security to branch offices and remote sites. It has no internal modem and provides five GbE RJ45 ports, each configurable as WAN or LAN in software.

The compact indoor unit suits wall-mount or desktop deployment and is powered by a 12V/2A external adapter. It supports thin-edge deployments with secure internet access over a backhaul connection to FortiSASE, making it a practical option for distributed sites managed centrally from a FortiGate.

Features

- Extends the FortiGate LAN interface over a secured L2 tunnel
- Layer 2 to Layer 7 security for branch offices
- Supports thin-edge deployment with secure internet access over a backhaul connection to FortiSASE
- Each of the 5 GbE ports can be set as WAN or LAN by software
- Compact wall-mount or desktop indoor design

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 5 x GbE RJ45 ports, each configurable as WAN or LAN
- Ethernet-only model, no internal modem
- No external antennas
- Wall-mount or desktop, indoor
- Dimensions: 27 x 180 x 99.9 mm
- Weight: 0.46 kg
- Power: 12V/2A external adapter
- Max power consumption: 6.19 W at -5°C, 6.81 W at 50°C
- Operating temperature: 0-40°C
- Storage temperature: -20 to 70°C
- Humidity: 5-95%
- Bluetooth 2.4 GHz, max transmit power 10 dBm
- Certifications: FCC Part 15 Subpart B, ICES-003, CE, UL, CB, IC

FAQs

Q: Does the FortiExtender 200F include a cellular modem?
A: No. The FEX-200F is an Ethernet-only model with no internal modem and no external antennas. It connects over its five GbE RJ45 ports.

Q: Can the five Ethernet ports be used as WAN or LAN?
A: Yes. Each of the five GbE RJ45 ports can be configured as WAN or LAN by software.

Q: What does the FortiExtender 200F connect to?
A: It extends the FortiGate LAN interface, connecting to a FortiGate over a secured Layer 2 tunnel to provide Layer 2 to Layer 7 security at branch offices.

Q: Can it be used in a thin-edge deployment?
A: Yes. It supports thin-edge deployments with secure internet access over a backhaul connection to FortiSASE.

Q: How is the FEX-200F powered and mounted?
A: It runs from a 12V/2A external power adapter and can be wall-mounted or placed on a desktop for indoor use.

Q: What operating temperature range does it support?
A: The operating temperature range is 0 to 40°C, with humidity of 5 to 95 percent.
