Dell

Dell R470 | PowerEdge R470 1U Rack Server, Xeon 6, 16x DDR5

Dell R470 | PowerEdge R470 1U Rack Server, Xeon 6, 16x DDR5

Authorised Dell Partner

R470

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Dell PowerEdge R470 is a 1U single-socket rack server built around an Intel Xeon 6 processor, designed to balance performance, power efficiency and cost for data centre and enterprise workloads. With 16 DDR5 DIMM slots running at speeds up to 6400 MT/s and flexible storage including EDSFF E3.S Gen5 NVMe and 2.5-inch SAS, SATA and NVMe drives, it suits compact deployments where rack space is at a premium.

Hot-swap redundant power supplies and fans, an integrated BMC with a dedicated 1GbE management port and optional GPU support make the R470 a practical platform for virtualisation, general-purpose compute and edge workloads. Its 42.8 mm chassis height keeps the footprint small without sacrificing serviceability.

Features

- Optimised for energy efficiency and performance per watt
- Dell Smart Power and Cooling technology
- Hot-swappable redundant power supplies and fans
- Flexible storage options, including EDSFF E3.S Gen5 NVMe
- Integrated BMC for system management
- Suited to data centres with a compact footprint

Warranty

Dell hardware typically includes a 1 to 3-year limited hardware warranty, depending on the product model and configuration. Coverage includes repair or replacement for defects in materials and workmanship.

Extended Warranty Options:
Extended warranty and support packages are available through IP Trading. Contact us to customise a solution for your Dell infrastructure.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1U single-socket rack server
- One Intel Xeon 6 processor (E-core up to 144 cores; P-core up to 86 cores with R1S option)
- 16 x DDR5 DIMM slots, RDIMM only (registered ECC), speeds up to 6400 MT/s
- Storage: EDSFF E3.S Gen5 NVMe SSDs or 2.5-inch SAS/SATA/NVMe drives
- Power supplies: 800W Platinum or 1500W Titanium, hot-swap redundant, 100-240 VAC or 240 HVDC
- Air cooling with up to 4 sets (dual fan module) of hot-swappable fans
- Front ports: 1 x USB 2.0 Type-C; optional 1 x USB 2.0 Type-A, Mini-DisplayPort and DB9 serial
- 1GbE dedicated BMC Ethernet port
- Height 42.8 mm (1.69 inches)

FAQs

Q: What processor does the Dell PowerEdge R470 use?
A: The R470 is a single-socket server supporting one Intel Xeon 6 processor, with E-core options up to 144 cores and P-core options up to 86 cores on the R1S option.

Q: What type of memory does the R470 support?
A: It has 16 DDR5 DIMM slots and supports registered ECC RDIMMs only, at speeds up to 6400 MT/s.

Q: What storage options are available in the R470?
A: The R470 supports EDSFF E3.S Gen5 NVMe SSDs or 2.5-inch SAS, SATA and NVMe drives, depending on the chassis configuration selected.

Q: Does the R470 have redundant power supplies?
A: Yes. It uses hot-swap redundant power supplies, available as 800W Platinum or 1500W Titanium units, supporting 100-240 VAC or 240 HVDC input.

Q: How is the R470 managed remotely?
A: It includes an integrated BMC with a dedicated 1GbE Ethernet management port for remote system management.

Q: How much rack space does the R470 need?
A: The R470 is a 1U server with a chassis height of 42.8 mm (1.69 inches), suited to dense rack deployments.
