Dell R360 | PowerEdge R360 1U Rack Server, Xeon E-2400, DDR5

Authorised Dell Partner

SKU:R360

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Dell PowerEdge R360 is a 1U single-socket rack server built for SMBs, branch offices and near-edge deployments. It supports one Intel Xeon 6300 series or Xeon E-2400 series processor, or an Intel Pentium G7400, paired with DDR5 UDIMM memory up to 128GB across 4 slots.

Storage options include up to 8 x 2.5" or 4 x 3.5" SAS/SATA drives, with an optional hot-plug BOSS-N1 module for M.2 boot. Dual redundant power supplies, integrated iDRAC remote management, two 1GbE ports and a Gen4 PCIe riser make it a dependable platform for productivity and data-intensive workloads in a compact chassis.

Features

- Integrated Dell Remote Access Controller (iDRAC) for remote management
- High-speed DDR5 memory and NVMe BOSS-N1 boot optimisation for lower latency
- Redundant power supplies for improved uptime
- Optional GPU support for video and audio workloads
- Suited to productivity and data-intensive applications for growing businesses

Warranty

Dell hardware typically includes a 1 to 3-year limited hardware warranty, depending on the product model and configuration. Coverage includes repair or replacement for defects in materials and workmanship.

Extended Warranty Options:
Extended warranty and support packages are available through IP Trading. Contact us to customise a solution for your Dell infrastructure.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1U rack form factor, 1 processor socket
- One Intel Xeon 6300 series or Xeon E-2400 series processor, or one Intel Pentium G7400/G7400T (2 cores)
- 4 x DDR5 UDIMM slots, up to 128GB, up to 4400 MT/s
- Up to 8 x 2.5" SAS/SATA drives, or up to 4 x 3.5" SAS/SATA drives
- Up to 6 x 2.5" SAS/SATA drives via PERC plus 2 x 2.5" direct-attach NVMe drives
- Internal storage controllers: HBA355i, PERC H355, PERC H755
- Optional hot-plug BOSS-N1 with 2 x M.2 SSDs for boot
- Two redundant AC or DC power supply units
- 2 x integrated 1GbE ports plus a dedicated iDRAC Ethernet port
- Gen4 riser with 2 x PCIe Gen4 slots (x8 and x16, half-length)
- Supports 1 x NVIDIA A2 60W single-width GPU
- Chassis height 42.8 mm

FAQs

Q: What processors does the Dell PowerEdge R360 support?
A: It supports one Intel Xeon 6300 series or Xeon E-2400 series processor, or an Intel Pentium G7400/G7400T, in a single-socket configuration.

Q: How much memory can the R360 hold?
A: It has 4 DDR5 UDIMM slots supporting up to 128GB at speeds up to 4400 MT/s.

Q: What storage configurations are available?
A: Up to 8 x 2.5" SAS/SATA drives or up to 4 x 3.5" SAS/SATA drives, or up to 6 x 2.5" SAS/SATA drives plus 2 x 2.5" direct-attach NVMe drives.

Q: Does the R360 support redundant power?
A: Yes. It supports two redundant AC or DC power supply units.

Q: Can a GPU be installed in the R360?
A: Yes. It supports one NVIDIA A2 60W single-width GPU via the Gen4 riser.

Q: What remote management is included?
A: The server includes the integrated Dell Remote Access Controller (iDRAC) with a dedicated iDRAC Ethernet port for out-of-band management.
