• APC APTF10KW01 10kVA rack isolation transformer with HP server rack front panel
1 1

APC

APC APTF10KW01 | 10kVA 4U Rack Isolation Step-Down Transformer, Hardwired

APC APTF10KW01 | 10kVA 4U Rack Isolation Step-Down Transformer, Hardwired

Authorised APC Partner

APTF10KW01

Stock Status: Enquire

$5,616.73 inc. GST
$5,106.12 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC APTF10KW01 is a 10kVA rack-mount isolation step-down transformer in a 4U chassis, designed for hardwired installation. It converts a 208/230/240V input to a 120/208/230/240V output, making it suited to server rooms and data centres that need to match site power feeds to equipment voltage requirements.

Placed upstream of a Smart-UPS, the transformer helps absorb inrush current and avoid saturation, so the UPS does not need to be oversized. Input and output connections are hardwired, and the unit ships with rack mounting brackets, a hardwire panel, mounting hardware, an installation guide and user documentation.

Features

- Supports step-down, step-up or isolation of power feeds
- Installs upstream of a Smart-UPS to limit inrush current and avoid UPS oversizing
- Rack-mountable with horizontal, vertical and toolless mounting options
- Hardwired input and output for permanent installation
- UL and CSA approved
- Includes rack mounting brackets, hardwire panel, installation guide, user manual, documentation CD and mounting hardware

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

FAQs

APC Replacement Battery Finder

Technical Specifications

- Load capacity: 10 kVA (10,000 VA)
- Nominal input voltage: 208 V / 230 V / 240 V
- Nominal output voltage: 120 V / 208 V / 230 V / 240 V
- Input frequency: 45-65 Hz
- Input connections: hardwire 3-wire (2PH + G) or 3-wire (1PH + N + G)
- Output connections: hardwire 3-wire (H N + G) or 3-wire (2PH + G)
- Maximum line current: 60 A per phase
- Efficiency: 95%
- Form factor: 4U rack-mountable
- Dimensions (H x W x D): 175 x 432 x 749 mm
- Net weight: 100 kg
- Colour: Black
- Standards: C-tick, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, UL Listed, VDE

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What input and output voltages does the APTF10KW01 support?
A: It accepts a nominal 208, 230 or 240V input and delivers a nominal 120, 208, 230 or 240V output, with an input frequency range of 45-65 Hz.

Q: Can this transformer be used with a Smart-UPS?
A: Yes. It is designed to sit upstream of APC Smart-UPS units, where it reduces inrush current and avoids the need to oversize the UPS.

Q: Is the transformer plug-in or hardwired?
A: Both input and output connections are hardwired, so installation by a licensed electrician is required.

Q: How much rack space does it need and how heavy is it?
A: It occupies 4U of rack space and weighs 100 kg net, so ensure the rack and mounting position are rated for the load.

Q: What is the maximum current rating?
A: The maximum line and input current is 60 A per phase.

Q: What is included in the package?
A: The package includes rack mounting brackets, a hardwire panel, mounting hardware, an installation guide, a user manual and a documentation CD.
