• APC AP7921B black rack PDU with 10 outlets, digital display, lights
1 1

APC

APC AP7921B | NetShelter Switched Rack PDU, 1U, 16A, 8x C13, C20

APC AP7921B | NetShelter Switched Rack PDU, 1U, 16A, 8x C13, C20

Authorised APC Partner

AP7921B

In stock:30

$1,834.25 inc. GST
$1,667.50 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC AP7921B NetShelter switched rack PDU is a 1U, 16A, 208/230V power distribution unit with 8 IEC C13 outlets and a C20 input cord. Remote per-outlet on/off switching lets administrators reboot connected equipment without a site visit, while network management enables remote configuration and control. It delivers up to 3.7kW at 230V or 3.3kW at 208V from a single input.

A local current monitoring display with a visible overload warning, plus metering accuracy of +/- 5% (amps), supports capacity planning and load balancing. Multi-tier user access restricts unauthorised use of outlets, and the unit can be managed through EcoStruxure IT and other platforms. The horizontal 1U form factor suits standard 19-inch racks, with rack mounting brackets included.

Features

- Remote on/off outlet switching to reboot connected equipment
- Local current monitoring display with visible overload warning
- Network management for remote configuration and control
- Multi-tier user access to restrict unauthorised use of outlets
- Metering accuracy of +/- 5% (amps) for capacity planning and load balancing
- Single input power source for simple installation
- Managed via EcoStruxure IT and other platforms

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

Manual

FAQs

APC Replacement Battery Finder

Technical Specifications

- Model: AP7921B
- Type: Switched rack PDU, 1U, single phase
- Outlets: 8 x IEC 60320 C13
- Input connection: IEC 60320 C20 cord (approx. 2.5 m cord length)
- Max load: 3.7kW at 230V / 16A, or 3.3kW at 208V / 16A
- Input voltage: 200/208/230V AC
- Output voltage: 208/230V AC
- Mounting: 1U rack-mount, horizontal orientation
- Dimensions (approx.): 1.7in H x 17.5in W x 4.3in D
- Weight (approx.): 5 lb
- Includes: installation guide, user manual, rack mounting brackets

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: How many outlets does the AP7921B have and what type are they?
A: It provides 8 IEC 60320 C13 outlets, each individually switchable for remote on/off control.

Q: What input connection does this PDU use?
A: It uses an IEC 60320 C20 input cord of approximately 2.5 m, rated for 16A at 200/208/230V AC.

Q: What is the maximum load the AP7921B can supply?
A: It supports up to 3.7kW at 230V / 16A, or 3.3kW at 208V / 16A.

Q: Can I reboot individual devices remotely?
A: Yes. Per-outlet remote on/off switching through network management allows connected equipment to be rebooted without physical access to the rack.

Q: Is this a metered or switched PDU?
A: It is a switched PDU. It adds remote per-outlet switching to local current monitoring, with metering accuracy of +/- 5% (amps).

Q: Are rack mounting brackets included?
A: Yes. The unit ships with rack mounting brackets, an installation guide and a user manual for 1U horizontal mounting.
