• APC AP6120A NetShelter black metal rack PDU with 7 C13 and 2 C19 outlets
1 1

APC

APC AP6120A | NetShelter Basic Rack PDU, 7 C13 + 2 C19, 20A, C20

APC AP6120A | NetShelter Basic Rack PDU, 7 C13 + 2 C19, 20A, C20

Authorised APC Partner

AP6120A

Stock Status: Enquire

$170.78 inc. GST
$155.25 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC AP6120A NetShelter Basic Rack PDU is a non-metered, non-switched 0U/1U rack power distribution unit with 7 C13 and 2 C19 outlets, fed through an IEC 60320 C20 inlet. It supports 100-240V at up to 20A and 220-240V at a 16A rated line current, delivering 2300 VA of load capacity for servers, switches and network equipment in standard racks and cabinets.

The compact form factor can be mounted as a 1U unit or in a zero U orientation to preserve valuable rack space. A toolless mounting kit allows quick installation, and the mix of C13 and C19 outlets suits both standard IT equipment and higher-draw devices in a single PDU. Approved to cUL, UL, CE, EAC, IRAM, PSE and VDE, and RoHS and REACh compliant.

Features

- 7 C13 and 2 C19 outlets for extensive power distribution
- Zero U design for efficient use of rack space
- Supports up to 20A, 100 to 240V power distribution
- Includes toolless mounting kit for quick setup

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

Manual

FAQs

APC Replacement Battery Finder

Technical Specifications

- 7 x IEC 60320 C13 outlets and 2 x IEC 60320 C19 outlets (9 total)
- Input connection: IEC 60320 C20
- Input voltage: 100-240V
- Max line current 20A (100-240V); line rated current 16A (220-240V)
- Load capacity: 2300 VA
- Input frequency: 50/60 Hz
- PDU type: Basic
- Form factor: 1U / 0U
- Dimensions approx. 44 mm (H) x 388 mm (W) x 93 mm (D)
- Weight approx. 1.56 kg
- Approvals: cUL listed, CE, EAC, IRAM, PSE, UL listed, VDE
- RoHS and REACh compliant

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What outlets does the APC AP6120A provide?
A: It provides 7 x IEC 60320 C13 outlets and 2 x IEC 60320 C19 outlets, for a total of 9 outlets.

Q: What inlet does this PDU use?
A: Input is through an IEC 60320 C20 inlet, so you need a supply cord or upstream outlet with a matching C19 connector.

Q: Is the AP6120A a metered or switched PDU?
A: No. It is a Basic PDU, which means it distributes power without metering or per-outlet switching.

Q: What voltage and current does it support?
A: It supports 100-240V input at up to 20A, with a 16A rated line current at 220-240V and a load capacity of 2300 VA.

Q: Can it be mounted in either 0U or 1U orientation?
A: Yes. The unit supports both 1U and 0U (zero U) mounting, and a toolless mounting kit is included for quick setup.

Q: Who is this PDU suited to?
A: It suits server racks and cabinets that need simple, reliable power distribution for a mix of standard C13 equipment and higher-draw C19 devices without remote monitoring.
