• White Fortinet FG-600E back view with Ethernet ports and USB slots
1 1

Fortinet

Fortinet FG-600E | 600E Next-Gen Firewall, 36 Gbps, 2x 10G SFP+, No SSD

Fortinet FG-600E | 600E Next-Gen Firewall, 36 Gbps, 2x 10G SFP+, No SSD

Authorised Fortinet Partner

FG-600E

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiGate 600E is a 1RU enterprise next-generation firewall delivering 36 Gbps of IPv4 firewall throughput, 10 Gbps IPS throughput and 9.5 Gbps NGFW throughput. It combines firewall, IPS, application control, VPN and threat protection in a single appliance, with 2x 10GE SFP+ slots, 8x GE SFP slots and 8x GE RJ45 interfaces for flexible campus, data centre edge and large branch deployments. This FG-600E model has no local storage; the FG-601E sibling adds 2x 240 GB SSD.

SPU NP6 network processors and CP9 content processors accelerate traffic, keeping latency to 2 microseconds while handling 8 million concurrent sessions and 450,000 new sessions per second. FortiOS provides integrated SSL inspection, 20 Gbps IPsec VPN, SSL-VPN, high availability and integration with the Fortinet Security Fabric, and the unit ships with 2x 1GE SX SFP transceivers.

Features

- SPU NP6 network processor and CP9 content processor hardware acceleration
- FortiOS security-driven networking with integrated NGFW, IPS, application control and SSL inspection
- Integrates with the Fortinet Security Fabric
- Supports up to 64 FortiSwitches and 1,024 FortiAPs
- Active-Active, Active-Passive and clustering high availability
- Optional hot-swappable redundant power supplies
- FortiGuard security services bundles available
- Ships with 2x 1GE SX SFP transceivers

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 2x 10GE SFP+ slots
- 8x GE SFP slots
- 8x GE RJ45 interfaces plus 2x GE RJ45 management ports
- 2x USB ports, 1x RJ45 console port
- Local storage: none (non-SSD model)
- Includes 2x 1GE SX SFP transceivers
- IPv4 firewall throughput: 36 Gbps (1518-byte UDP)
- IPS throughput: 10 Gbps
- NGFW throughput: 9.5 Gbps
- Threat protection throughput: 7 Gbps
- IPsec VPN throughput: 20 Gbps
- SSL-VPN throughput: 7 Gbps
- SSL inspection throughput: 8 Gbps
- Concurrent sessions: 8 million
- New sessions per second: 450,000
- Firewall latency: 2 microseconds
- Form factor: 1 RU
- Power: 100-240V AC, 129 W average, 244 W maximum
- Dimensions: 44.45 x 432 x 380 mm, 7.3 kg

FAQs

Q: What is the difference between the FG-600E and FG-601E?
A: Both share the same ports and performance. The FG-600E has no local storage, while the FG-601E includes 2x 240 GB SSD.

Q: What network interfaces does the FortiGate 600E provide?
A: It has 2x 10GE SFP+ slots, 8x GE SFP slots, 8x GE RJ45 interfaces and 2x GE RJ45 management ports, plus USB and RJ45 console ports.

Q: Does the FG-600E include SFP transceivers?
A: Yes, it ships with 2x 1GE SX SFP transceivers. Additional 10G SFP+ optics are purchased separately.

Q: What is the NGFW throughput of the FortiGate 600E?
A: It delivers 9.5 Gbps NGFW throughput, 10 Gbps IPS throughput and 7 Gbps threat protection throughput, with 36 Gbps IPv4 firewall throughput.

Q: Does it support redundant power supplies?
A: Yes, hot-swappable redundant power supplies are available as an option.

Q: Can it be deployed in a high availability pair?
A: Yes, it supports Active-Active, Active-Passive and clustering high availability configurations.
