Moxa EDS-508A-SS-SC Managed Ethernet Switch With 6 10/100Baset(X) Ports, 2 100Basefx Single-Mode Ports With Sc Connectors, 0 To 60 C Operating Temperature

The Moxa EDS-508A-SS-SC is a robust managed Ethernet switch designed for industrial applications. Featuring six 10/100BaseT(X) ports and two 100BaseFX single-mode ports with SC connectors, it ensures reliable and high-speed network connections. Ideal for demanding environments, it operates flawlessly within a temperature range of 0 to 60°C. This switch offers advanced network management, enhanced security, and is engineered to deliver dependable performance in critical network infrastructures.

REQUEST A QUOTE today, and let us provide you with a prompt and professional response tailored just for you. Experience the highest standard of service at unbeatable prices.

Moxa EDS-508A-SS-SC Managed Ethernet Switch With 6 10/100Baset(X) Ports, 2 100Basefx Single-Mode Ports With Sc Connectors, 0 To 60 C Operating Temperature

Features

  • Managed Ethernet switch with advanced network management capabilities
  • 6 10/100BaseT(X) RJ45 ports for flexible network extension
  • 2 100BaseFX single-mode fiber ports with SC connectors for long-distance data transmission
  • Supports IEEE 802.3/802.3u/802.3x standards
  • Wide operating temperature range from 0 to 60°C
  • Redundant power inputs for enhanced reliability
  • DIN-rail and panel mounting options for easy installation
  • Advanced security features including VLAN, QoS, and port mirroring
  • Comprehensive LED indicators for easy network diagnostics

Technical Specifications

  • Model: EDS-508A-SS-SC
  • Ethernet Ports: 6 10/100BaseT(X) RJ45 ports
  • Fiber Ports: 2 100BaseFX single-mode SC connectors
  • Network Standards: IEEE 802.3, 802.3u, 802.3x
  • Switching Capacity: 1.6 Gbps
  • Packet Buffer Size: 1 Mbit
  • MAC Address Table Size: 8K entries
  • Operating Temperature: 0 to 60°C (32 to 140°F)
  • Input Voltage: 12 to 45 VDC, redundant dual inputs
  • Power Consumption: 7.68 W
  • Dimensions: 53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in)
  • Mounting: DIN-rail or panel mount
  • Certifications: FCC, CE, UL

Frequent Ask Questions

  • What are the main features of the Moxa EDS-508A-SS-SC Ethernet Switch?

    The Moxa EDS-508A-SS-SC Managed Ethernet Switch comes with 6 10/100BaseT(X) ports and 2 100BaseFX single-mode ports with SC connectors. It operates within a temperature range of 0 to 60°C. The switch also includes advanced management features to provide network stability and efficiency.

  • What type of ports does the Moxa EDS-508A-SS-SC have?

    The Moxa EDS-508A-SS-SC is equipped with 6 10/100BaseT(X) Ethernet ports and 2 100BaseFX single-mode fiber ports with SC connectors.

  • What is the operating temperature range of the Moxa EDS-508A-SS-SC?

    The Moxa EDS-508A-SS-SC can operate efficiently within a temperature range of 0 to 60 degrees Celsius.

  • Is the Moxa EDS-508A-SS-SC a managed switch?

    Yes, the Moxa EDS-508A-SS-SC is a managed Ethernet switch, allowing for advanced network management and configuration.

  • What connectors are used for the fiber ports on the Moxa EDS-508A-SS-SC?

    The fiber ports on the Moxa EDS-508A-SS-SC use SC connectors.

  • Can the Moxa EDS-508A-SS-SC be used in industrial environments?

    Yes, Moxa switches are designed for industrial environments where reliability and performance are critical. The EDS-508A-SS-SC can operate in challenging conditions within its specified temperature range.
