Ubiquiti UACC-SFP-Wizard | UniFi SFP Wizard SFP/QSFP Module Diagnostic Tool, Bluetooth

Authorised Ubiquiti Partner

SKU:UACC-SFP-Wizard

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Ubiquiti UniFi SFP Wizard UACC-SFP-Wizard is a pocket-sized, battery-powered SFP/QSFP module programmer and diagnostic tool for network engineers and installers. It reads, copies and writes optical transceiver profiles and shows live DDM diagnostics on a 1.9" touchscreen, with support for SFP, SFP+, SFP28, QSFP+ and QSFP28 modules.

The tool connects over Bluetooth Low Energy to the UniFi mobile app on iOS and Android, which provides OTA firmware updates. It can power up a module's laser for a link check without needing a switch or router, making it a practical bench and field tool for fibre deployments. It is not compatible with UISP Fiber/GPON optical modules or the UniFi SFP+ to RJ45 adapter.

Features

- Copy optical module profiles from supported SFP/QSFP modules
- Write or restore a profile to a Ubiquiti optical module (writing is limited to Ubiquiti modules)
- Monitor optical module health in real time via DDM (temperature, optical power)
- Power up a module's laser for a link check without a switch or router
- OTA firmware updates through the UniFi mobile app
- Pocket-sized, battery-powered design with USB-C charging

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Supports SFP, SFP+, SFP28, QSFP+ and QSFP28 modules (modules sold separately)
- Networking interface: Bluetooth Low Energy (BLE)
- 1.9" touchscreen LCM display
- Power: rechargeable Li-ion battery, 3.7V DC, 300mAh
- Charging: USB-C, 5V DC/0.5A
- Power consumption: 0.6W
- Battery life: up to 75 minutes of continuous SFP diagnostics with laser on, or 35 minutes with QSFP
- Buttons: (1) Power
- Dimensions: 90.8 x 52.1 x 20.2 mm (3.6 x 2.1 x 0.8")
- Weight: 84 g (3 oz)
- Enclosure: polycarbonate
- Operating temperature: 0 to 40°C (32 to 104°F)
- Operating humidity: 10 to 90% noncondensing
- NDAA compliant
- Certifications: FCC, IC, CE
- App requirements: UniFi iOS 10.29.1 or later; UniFi Android 10.30.2 or later

FAQs

Q: Which module types does the UniFi SFP Wizard support?
A: It supports SFP, SFP+, SFP28, QSFP+ and QSFP28 modules. The modules themselves are sold separately.

Q: Can it write profiles to any brand of optical module?
A: It can read and copy profiles from supported SFP/QSFP modules, but writing is limited to Ubiquiti optical modules.

Q: How does it connect to my phone?
A: It connects over Bluetooth Low Energy to the UniFi mobile app. The app requires UniFi iOS 10.29.1 or later, or UniFi Android 10.30.2 or later.

Q: How long does the battery last?
A: Up to 75 minutes of continuous SFP diagnostics with the laser on, or 35 minutes with QSFP modules. It recharges over USB-C.

Q: Can I test a fibre link without a switch or router?
A: Yes. The tool can power up a module's laser for a link check without needing a switch or router, and it shows live DDM readings such as temperature and optical power.

Q: Is it compatible with UISP Fiber/GPON modules?
A: No. It is not compatible with UISP Fiber/GPON optical modules or the UniFi SFP+ to RJ45 adapter.
