Moxa NPort IA5150AI-T | NPort IA5000A 1-Port RS-232/422/485 Device Server, 2 kV, -40 to 75°C

Authorised Moxa Partner

SKU:NPort IA5150AI-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort IA5150AI-T is a 1-port RS-232/422/485 serial device server from the NPort IA5000A series, built to connect serial industrial equipment to Ethernet networks. It provides 2 kV serial isolation and enhanced surge protection for the serial, LAN and power connections, and operates across a wide -40 to 75°C temperature range.

Two 10/100BaseT(X) RJ45 ports share a single IP address, letting you cascade Ethernet connections for simpler wiring. Dual 12 to 48 VDC power inputs, a rugged metal housing, DIN-rail mounting and ATEX and C1D2 hazardous location certification make it suited to harsh factory, utility and process environments. It supports TCP Server, TCP Client, UDP, Real COM, RFC2217, Reverse Telnet, Pair Connection and Ethernet Modem operation modes.

Features

- Enhanced surge protection for serial, LAN and power
- 2 kV isolation for serial signals
- Rugged screw-type terminal blocks for power and serial connectors
- C1D2 and ATEX certified for harsh industrial environments
- Cascading Ethernet ports for easy wiring
- Redundant DC power inputs
- Warning by relay output and email
- Low power consumption with built-in MiiNe CPU
- Wide operating temperature of -40 to 75°C
- Supports TCP Server, TCP Client, UDP, Real COM, RFC2217, Reverse Telnet, Pair Connection and Ethernet Modem modes

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x RS-232/422/485 serial port (DB9 male for RS-232, terminal block for RS-422/485)
- 2 x 10/100BaseT(X) Ethernet ports (RJ45), single IP address, auto MDI/MDI-X
- Ethernet magnetic isolation protection: 1.5 kV (built-in)
- Serial isolation: 2 kV
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS (RS-232 only), DTR/DSR (RS-232 only), XON/XOFF
- RS-485 pull high/low resistor: 1 kilo-ohm, 150 kilo-ohms
- RS-485 terminator: 120 ohms
- RS-485 data direction control: ADDC (automatic data direction control)
- Input voltage: 12 to 48 VDC, 2 power inputs, terminal block connector
- Input current: 225 mA @ 12 VDC
- Housing: Metal
- Dimensions: 36 x 105 x 140 mm (1.42 x 4.13 x 5.51 in)
- Weight: 475 g (1.05 lb)
- Installation: DIN-rail mounting, wall mounting (with optional kit)
- Operating temperature: -40 to 75°C
- Hazardous locations certification: ATEX, C1D2
- Safety: UL 508
- Green product: RoHS, CRoHS, WEEE

FAQs

Q: Which serial standards does the NPort IA5150AI-T support?
A: It has one serial port that supports RS-232, RS-422 and RS-485 (2-wire and 4-wire). RS-232 uses the DB9 male connector, while RS-422 and RS-485 use the terminal block.

Q: How much serial isolation does it provide?
A: The serial port has 2 kV isolation, and the Ethernet ports include built-in 1.5 kV magnetic isolation. It also includes enhanced surge protection for serial, LAN and power connections.

Q: What temperature range can it operate in?
A: It operates from -40 to 75°C, which suits unheated enclosures, outdoor cabinets and hot industrial sites.

Q: What power supply does it need and does it support redundancy?
A: It accepts 12 to 48 VDC and has two terminal block power inputs for redundant DC feeds. Input current is 225 mA at 12 VDC.

Q: What are the two Ethernet ports for?
A: The two 10/100BaseT(X) RJ45 ports share a single IP address and let you cascade devices on the same network segment, which simplifies wiring in a cabinet or along a machine line.

Q: Is it approved for hazardous locations and how is it mounted?
A: Yes, it is ATEX and C1D2 certified and carries UL 508 safety approval. It has a metal housing and mounts on a DIN rail, or on a wall with the optional mounting kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
