• Three Moxa NPort 5450AI-M12 4-port RS-232/422/485 device servers with M12 ports
1 1

Moxa

Moxa NPort 5450AI-M12 | 4-Port RS-232/422/485 Device Server, -25 to 55°C

Moxa NPort 5450AI-M12 | 4-Port RS-232/422/485 Device Server, -25 to 55°C

Authorised Moxa Partner

NPort 5450AI-M12

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa NPort 5450AI-M12 is a 4-port RS-232/422/485 serial device server that connects serial devices to Ethernet through an M12 10/100BaseT(X) network port and an M12 power input. This standard temperature model operates from -25 to 55°C with no conformal coating, making it well suited to rolling stock and other harsh, vibration-prone environments where reliable industrial connectivity is essential.

Each DB9 male serial port supports RS-232, RS-422, RS-485 2-wire and RS-485 4-wire modes. Windows Real COM and Linux Real TTY drivers, plus fixed TTY drivers, make integration into existing SCADA, control and monitoring systems straightforward. A built-in watchdog timer, buzzer and real-time clock support dependable unattended operation.

Features

- M12 connectors for Ethernet and power, giving vibration-resistant connections
- Supports RS-232, RS-422, RS-485 2-wire and RS-485 4-wire
- IGMP v1/v2 filtering
- Built-in watchdog for automatic reboot
- Built-in buzzer and real-time clock for alerts
- Wide driver support across Windows and Linux

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232/422/485 serial ports (DB9 male)
- 1 x 10/100BaseT(X) Ethernet port with M12 connector
- Power input: 12 to 48 VDC via M12 A-coded 5-pin male connector
- Input current: 440 mA @ 12 VDC
- Compliant with EN 50155 on 24/48 VDC
- Operating temperature: -25 to 55°C (-13 to 131°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- Built-in watchdog timer (WDT), buzzer and RTC
- Windows Real COM drivers and Linux Real TTY drivers; fixed TTY drivers
- Security: HTTPS, AES-128, RSA-1024, SHA-1/SHA-256, SNMPv3, TLS 1.2
- Configuration via Web Console (HTTP/HTTPS), Windows Utility, Device Search Utility (DSU), MCC Tool, Telnet

FAQs

Q: What serial interfaces does the NPort 5450AI-M12 support?
A: Its four DB9 male serial ports each support RS-232, RS-422, RS-485 2-wire and RS-485 4-wire.

Q: What type of network and power connectors does it use?
A: It has one 10/100BaseT(X) Ethernet port with an M12 connector and an M12 A-coded 5-pin male power input accepting 12 to 48 VDC.

Q: What is the operating temperature range of this model?
A: This standard temperature model operates from -25 to 55°C (-13 to 131°F) and does not have conformal coating.

Q: Is it suitable for rolling stock applications?
A: Yes. It is compliant with EN 50155 on 24/48 VDC and uses M12 connectors for vibration-resistant connections.

Q: Which operating systems and drivers are supported?
A: Windows Real COM drivers, Linux Real TTY drivers and fixed TTY drivers are supported.

Q: How is the device configured and secured?
A: Configuration is available through the Web Console (HTTP/HTTPS), Windows Utility, Device Search Utility, MCC Tool or Telnet. Security features include HTTPS, AES-128, SNMPv3 and TLS 1.2.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
