Moxa MiiNePort E2-H-ST | MiiNePort E2-H Starter Kit, Embedded Serial Device Server

Authorised Moxa Partner

SKU:MiiNePort E2-H-ST

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa MiiNePort E2-H-ST is a starter kit for the MiiNePort E2-H series of embedded serial-to-Ethernet device servers. It includes a MiiNePort E2-H module (10/100 Mbps, pin header, 0 to 55°C), an evaluation board and a universal power adapter, giving engineers everything needed to evaluate the module and develop custom applications around it.

The E2-H module is a compact drop-in design built on a 32-bit Arm core, with a TTL serial interface and built-in TCP/IP protocols and network enabling tools for fast integration. It suits OEMs and system integrators who want to network-enable existing serial devices, with Windows Real COM, Linux Real TTY and Android API driver support.

Features

- Complete starter kit with module, evaluation board and universal power adapter
- Evaluation board supports module evaluation and custom application development
- Built-in TCP/IP protocols and network enabling tools for fast integration
- Compact drop-in design for fitting into existing serial devices
- Web Console and Windows Utility configuration
- Windows Real COM, Linux Real TTY and Android API driver support

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Kit contents: 1 MiiNePort E2-H module, 1 evaluation board, 1 universal power adapter
- 32-bit Arm core CPU
- 10/100 Mbps Ethernet, pin header module (no RJ45 connector on module)
- TTL serial interface, 50 bps to 921.6 Kbps baudrate
- Input voltage: 3.3 to 5 VDC
- Input current: 157 mA @ 3.3 VDC
- Operating temperature: 0 to 55°C
- Weight: 77 g (0.17 lb)
- Form factor: Drop-in module
- Configuration: Web Console (HTTP), Windows Utility
- Management: ARP, BOOTP, Device Search Utility (DSU), DHCP Client, IPv4, SMTP, SNMPv1, TCP/IP, Telnet, TFTP, UDP, ICMP
- Drivers: Windows Real COM, Linux Real TTY (kernel 2.4.x to 5.x), Fixed TTY for several UNIX variants, Android API 3.1.x and later

FAQs

Q: What is included in the MiiNePort E2-H-ST starter kit?
A: The kit includes one MiiNePort E2-H module, one evaluation board and one universal power adapter.

Q: Who is this starter kit intended for?
A: It is intended for engineers and OEMs who want to evaluate the MiiNePort E2-H module and develop applications around it before integrating it into a serial device.

Q: Does the E2-H module have an RJ45 connector?
A: No. The E2-H is a 10/100 Mbps pin header module without an RJ45 connector on the module itself.

Q: What serial interface and baudrate does the module support?
A: The module uses a TTL serial interface with baudrates from 50 bps to 921.6 Kbps.

Q: What operating systems are supported for virtual COM or TTY drivers?
A: Windows Real COM, Linux Real TTY (kernel 2.4.x to 5.x), Fixed TTY for several UNIX variants, and Android API 3.1.x and later.

Q: What is the operating temperature range of the module?
A: The E2-H module operates from 0 to 55°C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
