Moxa ioLogik E2260-T | ioLogik E2260 Ethernet Remote I/O, 6 x RTD, 4 x DO, -40 to 75°C

Authorised Moxa Partner

SKU:ioLogik E2260-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioLogik E2260-T is a smart Ethernet remote I/O unit from the ioLogik E2200 series, built for temperature monitoring and control in demanding industrial sites. It provides 6 x RTD inputs (2- or 3-wire) and 4 x sink-type digital outputs, and the wide-temperature design operates from -40 to 75°C. Front-end intelligence through Click&Go control logic (up to 24 rules) lets the unit act on sensor readings locally without waiting on a central controller.

A 10/100BaseT(X) RJ45 port and an RS-485 serial port (Modbus RTU Master) connect the unit to field devices and the network. It supports Modbus TCP, SNMP v1/v2c/v3, peer-to-peer communication and MX-AOPC UA Server, and can be configured through the ioAdmin Windows utility or a web console. Power input is 12 to 36 VDC, with DIN-rail or wall mounting.

Features

- Front-end intelligence with Click&Go control logic, up to 24 rules
- Active communication with MX-AOPC UA Server
- Peer-to-peer communication saves time and wiring costs
- Supports SNMP v1/v2c/v3 for network management
- Web browser and ioAdmin utility configuration
- MXIO library for Windows or Linux integration
- Wide operating temperature range of -40 to 75°C

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x RTD channels (2- or 3-wire)
- 4 x digital outputs, sink type, 200 mA per channel
- 1 x 10/100BaseT(X) RJ45 port
- 1 x RS-485-2w serial port, Modbus RTU Master, 1200 to 115200 bps
- RTD resolution 0.1°C or 0.1 ohms, 12 samples/sec across all channels
- RTD accuracy ±0.1% FSR at 25°C
- Isolation: 3k VDC or 2k Vrms
- Input voltage 12 to 36 VDC, 95 mA at 24 VDC
- Click&Go control logic, up to 24 rules
- Protocols: Modbus TCP Server (Slave), SNMPv1/v2c/v3, SNMPv1 Trap, Moxa AOPC, MXIO Library
- Real-time clock with battery backup, SNTP time sync
- Dimensions 115 x 79 x 45.6 mm, weight 250 g
- DIN-rail and wall mounting
- Operating temperature -40 to 75°C, storage -40 to 85°C
- Humidity 5 to 95% non-condensing
- MTBF 327,282 hrs (Telcordia SR332)
- Safety: UL 508

FAQs

Q: What RTD sensor types does the ioLogik E2260-T support?
A: It supports sensor types including PT50, PT100, PT200, PT500, PT1000, JPT100, JPT200, JPT500, JPT1000, NI100, NI120, NI200, NI500 and NI1000, plus resistance inputs of 310, 620, 1250 and 2200 ohms.

Q: Are the RTD inputs 2-wire or 3-wire?
A: Both. The RTD channels accept 2-wire or 3-wire connections.

Q: What type of digital outputs does it have?
A: It has 4 sink-type digital outputs rated 200 mA per channel, usable as standard DO or pulse output at up to 1 kHz.

Q: Which protocols does the unit support?
A: Modbus TCP Server (Slave), SNMP v1/v2c/v3, SNMPv1 Trap, Moxa AOPC (Active Tag), MXIO Library and CGI commands. The serial port acts as a Modbus RTU Master.

Q: What is the power requirement?
A: It runs from a 12 to 36 VDC supply on a single power input, drawing 95 mA at 24 VDC.

Q: Can it operate in extreme temperatures?
A: Yes. The -T model operates from -40 to 75°C, suitable for outdoor cabinets and unheated industrial environments.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
