Moxa CP-104UL-T | CP-104UL/104JU 4-Port RS-232 Universal PCI Serial Board, -40 to 85°C

Authorised Moxa Partner

SKU:CP-104UL-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CP-104UL-T is a 4-port RS-232 low-profile Universal PCI serial board built for POS, ATM and industrial PC deployments. This wide-temperature model is rated for -40 to 85°C and ships without a cable, using a DB44 female connector for the serial breakout. It delivers baudrates up to 921.6 kbps with over 800 kbps of real data throughput.

The 32-bit Universal PCI design is compatible with 3.3/5 V PCI and PCI-X slots, and up to 8 boards can be installed in a single PC for high-density serial expansion. Drivers are available for Windows, Linux and UNIX, and full modem control signals support a wide range of serial peripherals.

Features

- Over 800 kbps data throughput for top performance
- 921.6 kbps maximum baudrate for fast data transmission
- 128-byte FIFO and on-chip H/W, S/W flow control
- Compatible with 3.3/5 V PCI and PCI-X slots
- Drivers provided for Windows, Linux, and UNIX
- Full modem control signals for compatibility with a wide range of serial peripherals
- Wide-temperature model for -40 to 85°C environments

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232 serial ports
- 32-bit Universal PCI bus (3.3/5 V PCI and PCI-X compatible)
- DB44 female connector (CP-104UL models), no cable included
- MU860 communication controller (16C550C compatible)
- 128-byte FIFO
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Up to 8 boards per PC
- Operating temperature -40 to 85°C
- Supported OS: Windows, Linux, UNIX
- Certifications: CE, FCC
- 5-year warranty

FAQs

Q: Does the CP-104UL-T include a cable?
A: No. This model has a DB44 female connector and is supplied without a cable, so a compatible DB44 to DB9 or DB25 breakout cable is required to connect serial devices.

Q: What operating temperature does the CP-104UL-T support?
A: The -T suffix indicates the wide-temperature version, rated for operation from -40 to 85°C.

Q: Which PCI slots is this board compatible with?
A: It is a 32-bit Universal PCI board compatible with both 3.3 V and 5 V PCI slots, as well as PCI-X.

Q: How many CP-104UL-T boards can be installed in one PC?
A: Up to 8 boards can be installed in a single PC, giving up to 32 RS-232 ports.

Q: Which operating systems are supported?
A: Drivers are provided for Windows, Linux and UNIX.

Q: What is the maximum baudrate?
A: The board supports baudrates from 50 bps up to 921.6 kbps, with over 800 kbps of data throughput.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
