Moxa ioPAC 8600-CPU30-RJ45-IEC-T | ioPAC 8600 CPU30 Rugged Controller, 2x RJ45, IEC 61131-3

Authorised Moxa Partner

SKU:ioPAC 8600-CPU30-RJ45-IEC-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioPAC 8600-CPU30-RJ45-IEC-T is a rugged modular controller CPU module built around a 32-bit 1 GHz Cortex-A8 processor running real-time Linux (PREEMPTRT). It provides two 10/100BaseT(X) RJ45 Ethernet ports and is programmed with IEC 61131-3 control logic, making it suited to industrial automation, rail and other demanding deployments where -40 to 75°C operation is required.

This CPU module is part of the modular ioPAC 8600 platform and must be paired with a separate backplane (BM005, BM009 or BM012), a PW10 power module and I/O modules. It includes 512 MB of SDRAM, onboard eMMC storage and a microSD slot for expansion, supports Modbus TCP client and server alongside Modbus RTU/ASCII, and carries railway (EN 50121-4, EN 50155) and UL 508 approvals.

Features

- 1 GHz Cortex-A8 CPU shortens cycle time and allows more programs to run simultaneously
- IEC 61131-3 programming language support
- Ethernet bypass or dual-MAC jumper-selectable operation
- Wide -40 to 75°C operating temperature range
- Railway certifications (EN 50121-4, EN 50155) and UL 508
- Modular design with separate backplane, power and I/O modules
- Real-time clock with capacitor backup

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: 32-bit Cortex-A8 1 GHz
- OS: Real-time Linux (PREEMPTRT)
- Memory: 512 MB DDR3(L) SDRAM, 128 KB SPI-NVRAM
- Storage: eMMC 4 GB (HW Rev 1.0.1) or 8 GB (HW Rev 1.1.0), microSD slot up to 32 GB
- Control logic language: IEC 61131-3
- Ethernet: 2 x 10/100BaseT(X) RJ45, 1 or 2 MAC addresses (jumper selectable)
- Magnetic isolation protection: 1.5 kV built-in
- Console port: RS-232, 3-pin (115200, n, 8, 1)
- Protocols: Modbus TCP client/server, Modbus RTU/ASCII, SNMPv1/v2c/v3, SNTP, SMTP, BOOTP
- Security: SSH, SNMPv3, AES-256, SHA-256, local database authentication
- Power consumption: 223 mA at 24 VDC
- Housing: metal, 148 g
- Operating temperature: -40 to 75°C
- Storage temperature: -40 to 85°C
- Humidity: 5 to 95% non-condensing
- Approvals: EN 50121-4, EN 50155, UL 508

FAQs

Q: What else is needed to run the ioPAC 8600-CPU30-RJ45-IEC-T?
A: It is a CPU module only. You need a backplane (BM005, BM009 or BM012), a PW10 power module and the required I/O modules, all sold separately.

Q: Which programming language does this controller use?
A: It supports IEC 61131-3 control logic, with configuration of the Ethernet settings via the RTUxpress Windows utility.

Q: How many Ethernet ports does it have and how are they configured?
A: It has two 10/100BaseT(X) RJ45 ports. A jumper selects either one MAC address (Ethernet bypass) or two MAC addresses.

Q: Which industrial protocols are supported?
A: Modbus TCP client and server, Modbus RTU/ASCII master and slave, Moxa AOPC active tag, and SNMPv1/v2c/v3.

Q: What operating temperature range does it support?
A: The operating range is -40 to 75°C, with storage from -40 to 85°C and 5 to 95% non-condensing humidity.

Q: Does it carry railway or safety approvals?
A: Yes, it is certified to EN 50121-4 and EN 50155 for railway use and UL 508 for safety.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
