Moxa ioPAC 8600-CPU30-M12-IEC-T | ioPAC 8600 Rugged Controller CPU Module, CPU30, 2x M12, IEC 61131-3

Authorised Moxa Partner

SKU:ioPAC 8600-CPU30-M12-IEC-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioPAC 8600-CPU30-M12-IEC-T is a rugged controller CPU module for Moxa's ioPAC 8600 modular programmable controller platform. Built around a 32-bit Cortex-A8 1 GHz CPU with 512 MB SDRAM, it provides two M12 D-coded 10/100 Ethernet ports and IEC 61131-3 control logic programming, and it operates across a -40 to 75°C temperature range.

The real-time Linux (PREEMPTRT) platform supports larger eMMC storage for more communication protocols, such as a RESTful API for railway IIoT or DNP3 outstations for oil and gas. A metal housing, 24 to 110 VDC power input and EN 50121-4 and EN 50155 railway certifications make it suited to demanding rail, energy and industrial automation environments.

Features

- 1 GHz Cortex-A8 CPU shortens cycle time and runs more programs at once
- Larger eMMC storage supports more protocols, such as RESTful API for railway IIoT and DNP3 for oil and gas
- Up to 1.7 GB of user storage for more complex programs
- Programs can be developed directly on the ioPAC
- Two M12 D-coded Ethernet ports for vibration-resistant connections
- Wide -40 to 75°C operating temperature range
- Railway certifications (EN 50121-4, EN 50155)
- Wall-mount installation design with metal body

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: 32-bit Cortex-A8 1 GHz
- OS: Real-time Linux (PREEMPTRT)
- SDRAM: 512 MB DDR3(L)
- eMMC: 4 GB (HW Rev. 1.0.1) or 8 GB (HW Rev. 1.1.0)
- SPI-NVRAM: 128 KB
- microSD slot: up to 32 GB (SD 2.0 compatible)
- Control logic language: IEC 61131-3
- Ethernet: 2 x 10/100BaseT(X), M12 D-coded 4-pin female
- Magnetic isolation protection: 1.5 kV (built-in)
- Serial: 1 x RS-232 console port, 3-pin (115200, n, 8, 1)
- Input voltage: 24 to 110 VDC
- Power consumption: 223 mA @ 24 VDC
- Power connector: spring-type Euroblock terminal
- Security protocols: SNMPv3, SSHv2
- Encryption: AES-256, HMAC, RSA-1024, SHA-1, SHA-256
- Housing: metal
- Weight: 181 g (0.40 lb)
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- Standards: EN 50121-4, EN 50155, UL 508, IEC 60068-2-27, IEC 60068-2-6

FAQs

Q: What programming standard does the ioPAC 8600-CPU30-M12-IEC-T use?
A: It uses IEC 61131-3 control logic, and programs can be developed directly on the ioPAC.

Q: What type of Ethernet ports does this CPU module have?
A: It has two 10/100BaseT(X) M12 D-coded 4-pin female ports, with 1 MAC address (Ethernet bypass) or 2 MAC addresses selectable by jumper.

Q: What is the operating temperature range?
A: The module operates from -40 to 75°C. Industrial-grade wide-temperature microSD cards are required if a microSD card is used in extreme temperatures.

Q: What input power does it require?
A: It accepts 24 to 110 VDC through a spring-type Euroblock terminal and draws 223 mA at 24 VDC.

Q: Which railway standards does it meet?
A: It is certified to EN 50121-4 and EN 50155 for railway applications, and also to UL 508 for safety.

Q: How much storage and memory does it have?
A: It has 512 MB SDRAM and eMMC storage of 4 GB (HW Rev. 1.0.1) or 8 GB (HW Rev. 1.1.0), with a microSD slot supporting cards up to 32 GB.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
