Moxa ioPAC 8600-CPU30-M12-C-T | ioPAC 8600 CPU Module, 1GHz, 2x M12, C/C++, -40 to 75C

Authorised Moxa Partner

SKU:ioPAC 8600-CPU30-M12-C-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ioPAC 8600-CPU30-M12-C-T is a rugged modular controller CPU module for the ioPAC 8600 series, built around a 32-bit Cortex-A8 1 GHz processor with two M12 D-coded 10/100 Ethernet ports. It is programmed in C/C++ on real-time Linux and operates across a -40 to 75°C temperature range, making it suited to railway, transport and other harsh industrial control deployments.

The module offers 512 MB SDRAM, onboard eMMC storage and a microSD slot for expansion up to 32 GB. The Ethernet ports support Ethernet bypass or dual-MAC mode by jumper selection, and the module supports Modbus TCP and Modbus RTU/ASCII in master and slave modes. Built-in security includes SSHv2, SNMPv3 and AES-256 encryption, and the housing is metal with EN 50121-4 and EN 50155 railway certification.

Features

- Rugged modular programmable controller CPU module
- Programmable in C/C++ on real-time Linux
- Two M12 D-coded Ethernet ports with Ethernet bypass or dual-MAC mode
- Wide operating temperature range of -40 to 75°C
- Railway certifications EN 50121-4 and EN 50155
- Built-in security with SSHv2, SNMPv3 and AES-256 encryption
- Modbus TCP and Modbus RTU/ASCII master and slave support

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: 32-bit Cortex-A8 1 GHz
- OS: Real-time Linux (PREEMPTRT)
- SDRAM: 512 MB
- SPI-NVRAM: 128 KB
- microSD slot: up to 32 GB (SD 2.0 compatible)
- Control logic language: C/C++
- Ethernet: 2 x 10/100BaseT(X), M12 D-coded 4-pin female
- Ethernet mode: 1 MAC address (Ethernet bypass) or 2 MAC addresses, jumper selectable
- Magnetic isolation protection: 1.5 kV built-in
- Console port: RS-232, 3-pin (115200, n, 8, 1)
- Industrial protocols: Modbus TCP client/server, Modbus RTU/ASCII master/slave, Moxa AOPC, SNMPv1/v2c/v3
- Security: SSHv2, SNMPv3, AES-256, HMAC, RSA-1024, SHA-1, SHA-256
- Power consumption: 223 mA @ 24 VDC
- Housing: metal, 181 g
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Humidity: 5 to 95% non-condensing
- Certifications: EN 55032/35, EN 61000-6-2/-6-4, EN 50121-4, EN 50155, UL 508
- Shock and vibration: IEC 60068-2-27, IEC 60068-2-6

FAQs

Q: What programming language does the ioPAC 8600-CPU30-M12-C-T use?
A: It uses C/C++ control logic running on real-time Linux (PREEMPTRT).

Q: What operating temperature range does this module support?
A: It operates from -40 to 75°C. When running in extreme temperatures, an industrial-grade wide-temperature microSD card is required.

Q: What Ethernet connectivity does it provide?
A: Two 10/100BaseT(X) M12 D-coded 4-pin female ports, configurable by jumper for a single MAC address with Ethernet bypass or two MAC addresses.

Q: Which industrial protocols are supported?
A: Modbus TCP client and server, Modbus RTU/ASCII in master and slave modes, Moxa AOPC (Active Tag) and SNMPv1/v2c/v3.

Q: Is this module suitable for railway applications?
A: Yes, it carries EN 50121-4 and EN 50155 railway certifications, along with UL 508 safety approval.

Q: How much storage does it have?
A: It has 512 MB SDRAM and onboard eMMC (4 GB or 8 GB depending on hardware revision), plus a microSD slot supporting cards up to 32 GB.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
