Moxa ioLogik E2210 | ioLogik E2200 Ethernet Remote I/O, 12 DI, 8 DO, Click&Go

Authorised Moxa Partner

SKU:ioLogik E2210

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ioLogik E2210 is an Ethernet remote I/O unit from the ioLogik E2200 series, providing 12 digital inputs and 8 sink-type digital outputs for factory, process and building automation. Built-in Click&Go control logic supports up to 24 rules for event-driven alarms and reports, so field I/O can react locally without a PLC. This standard temperature model operates from -10 to 60°C.

Communication options include Modbus TCP Server (Slave), SNMP v1/v2c/v3 and active push messaging to MX-AOPC UA Server, with a Modbus RTU Master RS-485 port for serial devices. It mounts on a DIN rail or wall and runs from a 12 to 36 VDC supply, with configuration through the ioAdmin utility or a web browser.

Features

- Click&Go front-end intelligence with up to 24 rules for local event-driven control
- Active communication with MX-AOPC UA Server
- Peer-to-peer communications reduce wiring and installation costs
- Supports Modbus TCP Server (Slave) and SNMP v1/v2c/v3
- Easy configuration via web browser or ioAdmin Windows utility
- MXIO library simplifies I/O management for Windows or Linux
- Over-current, over-temperature and over-voltage protection on outputs

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 12 x digital inputs (dry contact and wet contact NPN), DI or event counter mode
- 8 x digital outputs, sink type, 200 mA per channel, DO or pulse output mode
- 1 x 10/100BaseT(X) Ethernet port (RJ45) with 1.5 kV magnetic isolation
- 1 x RS-485 serial port (terminal block), 1200 to 115200 bps, Modbus RTU Master
- Control logic: Click&Go, up to 24 rules
- Counter frequency 900 Hz, pulse output frequency 1 kHz
- Isolation: 3k VDC or 2k Vrms
- Power input: 12 to 36 VDC, 202 mA @ 24 VDC
- Real-time clock with battery backup
- Operating temperature: -10 to 60°C
- Storage temperature: -40 to 85°C
- Humidity: 5 to 95% non-condensing
- Dimensions: 115 x 79 x 45.6 mm, weight 250 g
- DIN-rail or wall mounting, plastic housing
- Safety: UL 508, EMC: EN 61000-6-2/-6-4

FAQs

Q: How many inputs and outputs does the ioLogik E2210 have?
A: It provides 12 digital inputs (dry contact and wet contact NPN) and 8 sink-type digital outputs rated at 200 mA per channel.

Q: Which protocols does the ioLogik E2210 support?
A: It supports Modbus TCP Server (Slave), SNMP v1/v2c/v3 with SNMPv1 Trap, Moxa AOPC (Active Tag) push to MX-AOPC UA Server, the MXIO library and CGI commands. The serial port acts as a Modbus RTU Master.

Q: Can it operate without a PLC?
A: Yes. Click&Go control logic lets you build up to 24 rules for event-driven alarms and reports directly on the unit, without writing code.

Q: What power supply does it require?
A: It runs from a 12 to 36 VDC input via a Euroblock terminal and draws 202 mA at 24 VDC.

Q: What temperature range is this model rated for?
A: This is the standard temperature model, rated -10 to 60°C. Wide temperature (-T) models in the E2200 family cover -40 to 75°C.

Q: How is the ioLogik E2210 mounted and configured?
A: It mounts on a DIN rail or a wall. Configuration is done through the ioAdmin Windows utility or a web console over HTTP.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
